• Model NO.：D16L-4
• Material：Aviation Carbon Fiber and Aviation Aluminum
• Type：Sprayer Drone
• Sprayer Type：Pump
• Usage：Agriculture
• Applicable Industry：Farms,Home Use,Epidemic Prevention
• Feature：Anti-Fall
• Production Material：Aviation Carbon Fiber and Aviation Aluminum
• Production Folding Size：1100mm*1100mm*530mm
• Max Pesticide Load：16kg
• Aircraft Medicine Box Capacity：16L
• Flight Radius：Less Than 5000m
• Max Takeoff Weight：34kg
• Aircraft Weight：11kg
• Flight Attitude：Less Than 30m
• Flight Duration：20-25minutes
• Condition：New
• Warranty Time：12 Months
• Transport Package：Professional Package Box
• Specification：1 CBM
• Trademark：UNID
• Origin：China
• HS Code：8802200090
• Production Capacity：10000 Unit

Basic Info.

Model NO. D16L-4 Material Aviation Carbon Fiber and Aviation Aluminum Type Sprayer Drone Sprayer Type Pump Usage Agriculture Applicable Industry Farms,Home Use,Epidemic Prevention Feature Anti-Fall Production Material Aviation Carbon Fiber and Aviation Aluminum Production Folding Size 1100mm*1100mm*530mm Max Pesticide Load 16kg Aircraft Medicine Box Capacity 16L Flight Radius Less Than 5000m Max Takeoff Weight 34kg Aircraft Weight 11kg Flight Attitude Less Than 30m Flight Duration 20-25minutes Condition New Warranty Time 12 Months Transport Package Professional Package Box Specification 1 CBM Trademark UNID Origin China HS Code 8802200090 Production Capacity 10000 Unit

Product Description

Carbon fiber frame agricultural crop drone with night navigation function

- OEM  & ODM Service -
The closed fuselage structure could protect the U16L-4 from the rain and dust, and also could protect other load equipment. The new water-saving nozzles could save the pesticide and improve the efficiency of spraying at the same time. The capacity of Pesticide Barrel is 16L, and this can improve the efficiency of agriculture aircraft.The D16L-4 can sense cross lines and obstacles in the front 15 meters, which can effectively reduce the safety risks caused by common obstacles.

Model	D16L-4
Product material	Aviation carbon fiber + aviation aluminum
Product expansion size	1780mm*1780mm*600mm
Product folding size	1100mm*1100mm*530mm
Maximum take off weight	34KG
Aircraft weight	11KG
Pesticide Barrel	16L
Flight altitude	≤30 meters
Fly time(unloaded)	20~25 minutes
Fly time(loaded)	10~13 minutes when fully loaded
Flight speed	1-10 m / sec
Structure lift span	≥10 years
Spary width	4-8 meters
Hovering in the air	Hovering in any direction
Spray flow	3-8L/min double pump adjustable
Spray system	Imported high pressure anti-floating atomizing nozzle
Atomization point size	60~90μm
Fly Control	Industrial Version GPS and Controller
Spray efficiency	5~6hectares / hour
Safe takeoff and landing wind speed	≤5
Motor speed	5000rpm
Power system	48V power polymer computer battery
Charer	AC Input 100-240V
Lithium-polymer battery	16000mAh*1
