Safety and Reliable Price Cattle Feed Pellet Processing Production Line
Jiangsu Liangyou Zhengda Co., Ltd.- After-sales Service：Engineer Available
- Type：Feed Set
- Processing Object：Animal-Derived Feed
- Processing Technics：Crushing-before-Mixing
- Screen Mesh：With Screen Mesh
- Grinding Equipment Type：Feed Hammer Mill
Base Info
- Model NO.：FDSP
- Pellet Mill Type：Ring Die Pelleter
- Bulking Machine Type：Twin Screw Bulking Machine
- Expanding Method：Dry Expansion
- Condition：New
- Applicable Materials Shape：Granular
- Warranty：1 Year
- Voltage：380V,415V,440V
- Power(W)：700kw
- Dimension(L*W*H)：21*17.5*28m
- Capacity：20t,H
- Pelleted Feed Size：1.5-18mm
- Application：for Making Feed Pellets
- Transport Package：Iron Pallet and Soft Guard
- Specification：CE, ISO, SGS
- Trademark：FDSP
- Origin：China
- HS Code：84361000
- Production Capacity：1-3t,H
Description
1. Temperature: the temperature of the wet powder after conditioning, the temperature varies according to the formula (generally 4.5-ring die chicken feed temperature not less than 80 degrees, 3.0-ring die pig feed not less than 70 degrees, product adding enzyme temperature not more than 80 degrees) .
2. Moisture: before going into cooler, the moisture content of the particles after granulating. An effective test is to crush a hot particle between the thumb and forefinger into a pancake shape. If it is putty-like in viscosity and does not break, it indicates that the moisture content is in place; otherwise the steam still needs to be added.
3. Color: the color of the particles varies with the ingredients in the formula, and for the same formula (the same breed of formula) , the color will generally not change much.
4, particle size: the particle length usually is 2-3times of ring die diameter, according to different material number has different requirements.
Inspection on cooler
1. Temperature: after cooling the temperature of particles (generally for room temperature + 5 degrees) , through the detection of temperature here can find if cooler level adjustment is reasonable, cooler operation is normal.
2. Particle size: refers to the uniformity of the broken material, it can reflect whether the adjustment of the broken roller is normal, whether the roller is off-track phenomenon.
3, hardness: particle hardness is not high is the direct cause of the powder.
Inspection on packing section
1. Flour content: the percentage of 1.4 mm material after sifting
2. Heteromere: whether there are flower particles, mixed.
Inspection in lab
1. Moisture: use an infrared drying lamp to dry and detect moisture.
2. Use a pressure gauge to measure the hardness of the feed pellets.
3. Check the content of protein, fat and salt in feed.
4, all the indicators can be qualified for factory sales.
FDSP feed machinery and engineering, the use of scientific and mature design technology, so that feed final pellets are with length uniformity, hardness moderate, beautiful appearance, for customers to enhance market competitiveness. Welcome new and old customers call to negotiate.
About us
Jiangsu Liangyou Zhengda Co., Ltd. is professional in manufacturing feed machinery and projects. Our company is able to provide turn-key projects for all kinds of feed production like poultry feed, livestock feed, ruminant feed, ordinary aquatic feed, special aquatic feed, extruded aquatic feed, premix, pet food, etc.
Our service(Pre-sale and after-sales)
In pre-sale we provide users with comprehensive technical support. We provide comprehensive customer training, including in charge of the procedures, operating procedures, maintenance procedures, equipment, general maintenance, equipment, longterm hazard assessment knowledge and so on. Before the users buy our equipment, they must come to our company to accept a series of training. After the examination for equipment operation personnel, we will issue husbandry machinery operation qualification certificate. We suggest user to set up the remote control system. Our company after-sales service can guide the user through the remote control system for regular maintenance equipment key parts.
Packing&Shipping
Packaging:Depending on customers' requirement,such as wooden box or Iron crate etc.
Shipping:Our shipping operator and delivering equipment will be ready on time to ensure goods shipped based on Sales Order requirement.
Customers visiting
FDSP has exported Feed machinery to 30 countries including Korea, South Africa, Russia, Thailand, Taiwan, Philippines, Malaysia, Australia, Egypt, Syria, Nigeria, Ethiopia, India, Bangladesh, Pakistan, Iran etc.
