Agricultural Machinery

250*50.3 Insert Tooth Rubber Crawler

Shanghai Puyi Industrial Co., Ltd.
  • Type:Rotary Tiller
  • Application Field:Agriculture, Livestock, Aquaculture, Fisheries, Forestry
  • Farming Policy:Dry Cultivating Machinery
  • Power Source:Gasoline
  • Operation:Continuous Running Operation, Soil Preparation Machinery
  • with The Thickness of The Body:17mm

Base Info

  • Model NO.:PY-N250
  • The Decorative Pattern Thickness:28mm
  • Internal Teeth Height:23mm
  • Guide Teeth From The Outside:86mm
  • The Thickness of The Roller:85mm
  • Pitch Length:50.3mm
  • Width for Tracks:250mm
  • The Thickness of The Drive:35mm
  • Caterpillar:Teeth Crawler
  • Dedendum Width:33mm
  • Transport Package:Bare Package or Pallets
  • Specification:250*50.3*84
  • Trademark:No Marks or As buyer′s requests
  • Origin:Shanghai, China(Mainland)
  • HS Code:8431499900
  • Production Capacity:3000PCS,Month

Description

Basic Info.

Model NO. PY-N250 The Decorative Pattern Thickness 28mm Internal Teeth Height 23mm Guide Teeth From The Outside 86mm The Thickness of The Roller 85mm Pitch Length 50.3mm Width for Tracks 250mm The Thickness of The Drive 35mm Caterpillar Teeth Crawler Dedendum Width 33mm Transport Package Bare Package or Pallets Specification 250*50.3*84 Trademark No Marks or As buyer′s requests Origin Shanghai, China(Mainland) HS Code 8431499900 Production Capacity 3000PCS/Month

Product Description

Specifications
Continue Jointless Rubber Track Construct
Good Quality
Competitive Price
Prompt Shipment

Features:
1. Continuous Jointless Construct Rubber Track
2. Conventional Type or Interchangeable Type Rubber Track
3. Warranty: Guarantee 6 Months Against Manufacture Defects Under Normal Use
4. OEM Orders of complete track systems welcome
5. Comprehensive Range of Standard Rubber Crawler, Track System Available And Undercarriages Available For a Wide Range of Machinery
6. Application: Kubota Combined Harvester

More details:
(1). Less round damage
Rubber tracks cause less damage to roads than steel tracks, and less rutting of soft ground than either steel tracks of wheel products.
(2). Low noise
A benefit to equipment operating in congested areas, rubber track products less noise than steel tracks.
(3). High speed
Rubber track permit machines to travel at a higher speed than steel tracks.
(4). Less vibration
Rubber tracks insulate machine and operator from vibration, extending the machine's lifetime and lowering operate fatigue.
(5). Low ground pressure
The ground pressure of rubber tracks equipped machinery can be fairly low, about 0.14-2.30 kg/ cmm, a major reason for its use on the wet and soft terrain.
(6). Superior traction
The added traction of rubber, track vehicles permits them to pull twice the load of wheel vehicles of the sane weight.
Model NumberLinksPitch LengthWidthLengthWeight
PY-2508450.3mm250mm4225.2mm29.46kg
