Poultry Flat Die Feed Mill Sheep Cattle Food Pellet Machine
Zhengzhou Runxiang Machinery Equipment Co., Ltd.- Type:Pellet Mill
- Processing Object:Animal-Derived Feed
- Processing Technics:Crushing-before-Mixing
- Screen Mesh:With Screen Mesh
- Grinding Equipment Type:Feed Hammer Mill
- Pellet Mill Type:Flat Die Pelletizer
Base Info
- Model NO.:WSB series
- Bulking Machine Type:No Puffing
- Expanding Method:Wet Expansion
- Condition:New
- Applicable Materials Shape:Powder
- Material:Steel
- Capacity:100 Sets Per Month
- Application:Chicken, Pig, Cow, Birds, Fish, and So on
- Key Word:Poultry Feed Pellet Machine
- Transport Package:Wooden Cases
- Specification:ce co ccc
- Trademark:WSB
- Origin:Henan
- HS Code:8474802000
- Production Capacity:75-1100kg H
Description
Basic Info.
Model NO. WSB series Bulking Machine Type No Puffing Expanding Method Wet Expansion Condition New Applicable Materials Shape Powder Material Steel Capacity 100 Sets Per Month Application Chicken, Pig, Cow, Birds, Fish, and So on Key Word Poultry Feed Pellet Machine Transport Package Wooden Cases Specification ce co ccc Trademark WSB Origin Henan HS Code 8474802000 Production Capacity 75-1100kgHProduct Description
Poultry flat die feed mill sheep cattle food pellet machineIntroduction of feed pellet machine
1)This machine is used to make pellet for animal feed, such as pig, cattle, sheep, rabbit, chicken, duck, fish. it also can make bio-mass material wood pellet for fuel. |
2)The two roller twirls continuously to press and grind the raw material. |
3)This pellet machine is small volume, save the electricity, low noise and can transmission feeding speed. |
4)Our pellet mill have CE,ISO certificate. |
The raw material of feed pellet machine
1)It has wide range of materials, It can be grain like corn, wheat and the crushed waste from agriculture.such as sawdust, wood, straw, rice husk, bagasse, cotton stalk, peanut shell, bamboo, empty fruit branch, pulverized coal, waste paper, cottonseed skins, weeds, crop stalks and other plant wastes, especially low bonding and unformed materials and other can be making into biomass pellets without any additive. |
2)Requirements of the raw material size: 2~5 mm. moisture: 10-18%. |
1. Advantages:
It can make the fullest use of natural resources, have good rigidity, perfect smoothness, Long shelf life and standard degree of moistness.
2. Applied Range:
The wood pelletizer can be used for heat daily or mixed fodder by corn, beans, straw, grass meal, etc materials.
Type | Power | Weight(kg) | Packing size (mm) | Output | finished product size |
WSB -120A | 8hp | 120/140 | 870*440*730 | 75-100 | 4-6mm |
WSB -120B | 3KW | 80/100 | 750*320*510 | 75-100 | 4-6mm |
WSB -120BI | 2.2KW | 80/100 | 800*300*600 | 75-100 | 4-6mm |
WSB -150A | 8hp | 160/200 | 1100*500*950 | 100-200 | 4-6mm |
WSB -150B | 4KW | 95/115 | 750*350*650 | 100-200 | 4-6mm |
WSB -200A | 15hp | 240/270 | 1200*600*1000 | 200-300 | 4-8mm |
WSB -200B | 7.5KW | 240/270 | 1000*430*950 | 200-300 | 4-8mm |
WSB -230A | 22hp | 280/310 | 1180*580*880 | 300-400 | 4-8mm |
WSB -230B | 11KW | 290/320 | 1140*470*970 | 300-400 | 4-8mm |
WSB -260 | 15KW | 330/380 | 1200*500*1070 | 400-600 | 4-8mm |
WSB -300 | 22KW | 410/450 | 1250*520*1070 | 700-800 | 4-10mm |
WSB -360 | 22kw | 470/500 | 1270*520*1070 | 800-900 | 4-10mm |
WSB -400 | 30kw | 630/660 | 1470*600*1150 | 900-1100 | 4-10mm |
