• Model NO.：5XQS-10
• Customized：Available
• Cleaning Rate：98%
• Effect：Remove Stones, Heavy Impurity
• Delivery：25 Days
• Transport Package：Plywood Case Package or Mill′s Standard
• Specification：ISO9001: 2008, TUV, SGS
• Trademark：SYNMEC
• Origin：Hebei, China
• HS Code：84371090
• Production Capacity：10 Sets, Week

Basic Info.

Model NO. 5XQS-10 Customized Available Cleaning Rate 98% Effect Remove Stones, Heavy Impurity Delivery 25 Days Transport Package Plywood Case Package or Mill′s Standard Specification ISO9001: 2008, TUV, SGS Trademark SYNMEC Origin Hebei, China HS Code 84371090 Production Capacity 10 Sets/ Week

Product Description

Stones, Metallic Parts And Glass Splinters Extract Machine
Introduction

 Destoner is used to remove heavy foreign impurity like stone, metallic and glass pieces etc., on the principle of weight difference.

Principle

With the combination of fluidization and deck oscillation, heavy particles migrate to upper levels of the deck discharge from outlets and the light particles move to the lower level of the deck.

Features

The Destoner is the blow type destoner, which is not only widely applied for removing stone from all kinds of seeds and grains, also can be used in other fields such as remove stone from active carbon.

The Destoner is equipped with the Electromagnetic speed controller which can adjust the vibrating frequency of sieve table, as a result it has a perfect effect on removing stones.

Data


Model	5XQS-3 destoner	5XQS-5 destoner	5XQS-10 destoner
Capacity	3000 kg	5000 kg	10000 kg
Power	4.75 KW	7 KW	9.7 Kw
Dimension of Sieves	1260×1800 mm	1560×1800 mm	1680*1800mm
Dimension (L*W*H)	2200×1200×1600 mm	2500×1400×1600 mm	2500x2300x1600mm
Weight	600 kg	700 kg	900 kg
