• Model NO.：3WPX-800
• Power Supply：Tractor Shaft
• Type：Tractor Mounted Boom Sprayer
• Boom：12.5m
• Transport Package：Standard Package for Export
• Specification：2100x1250x2350mm
• Trademark：YAODA
• Origin：China
• HS Code：8424490000
• Production Capacity：500 PCS,Month

Basic Info.

Model NO. 3WPX-800 Power Supply Tractor Shaft Type Tractor Mounted Boom Sprayer Boom 12.5m Transport Package Standard Package for Export Specification 2100x1250x2350mm Trademark YAODA Origin China HS Code 8424490000 Production Capacity 500 PCS/Month

Product Description

Model	3WPX-650	3WPX-800	3WPX-1000	3WPX-1500
Power	≥30hp	≥50hp	≥70hp	≥100hp
Tank capacity	650L	800L	1000L	1500L
Mixing way	Jet mixing	Jet mixing	Jet mixing	Jet mixing
Folding way	Hydraulic folding and manual lifting	Hydraulic folding and manual lifting	Hydraulic folding and manual lifting	Hydraulic folding and manual lifting
System work pressure	0.3-0.5Mpa	0.3-0.5Mpa	0.3-0.5Mpa	0.3-0.5Mpa
5 Filtration system	Tank inlet, pump inlet and outlet ,nozzle,filter	Tank inlet, pump inlet and outlet ,nozzle,filter	Tank inlet, pump inlet and outlet ,nozzle,filter	Tank inlet, pump inlet and outlet ,nozzle,filter
Walking speed	4-20km/h	4-20km/h	4-20km/h	4-20km/h
Overall dimension	2100x1220x2350mm	2100x1250x2350mm	2100x1300x2350mm	2100x1350x2350mm
Weight	350KG	350KG	380KG	450KG
Pump type	Diaphragm pump  (4-cylinder)	Diaphragm pump (4-cylinder)	Diaphragm pump  (4-cylinder)	Diaphragm pump  (4-cylinder)
Pump pressure	2.5Mpa	2.5Mpa	2.5Mpa	2.5Mpa
Pump flow	150-160L/min	150-160L/min	150-160L/min	150-160L/min
Pump speed	600r/min	600r/min	600r/min	600r/min
Tank capacity	600L	800L	1000L	1500L
Boom	12.5m	12.5m	12.5m	12.5m
Spray height	0.5-1m	0.5-1m	0.5-1m	0.5-1m
Nozzle model	3 nozzle holders	3 nozzle holders	3 nozzle holders	3 nozzle holders
Spray angle	110 °	110 °	110 °	110 °
Nozzle flow	0.9-1.5L/min	0.9-1.5L/min	0.9-1.5L/min	0.9-1.5L/min
Clean water tank	5L	5L	5L	5L
