Zoomlion Old Used Square Baler for Wheat and Corn Straw Post-Processing Cheap Stock Machine
Zoomlion Heavy Industry Science & Technology Co., Ltd.- Type：Square Baler
- Automatic Grade：Automatic
- Power Source：Tractor
- Warranty：No Service
- Specification：6647*2820*1820mm
- Trademark：Zoomlion
Base Info
- Model NO.：9YF-1900C
- Origin：Anhui, China
- Production Capacity：10000sets,Year
Description
Basic Info.
Model NO. 9YF-1900C Origin Anhui, China Production Capacity 10000sets/YearProduct Description
9YF-1900C Square BalerHigh adaptability and reliability
Three groups of high strength transverse forced feeding fork structure, adapt to rice, wheat, grass, cut down corn straw baling operation;
Independent pickup hydraulic lifting system;
Wide picker to adapt to a larger, wider pile;
Strong piston is more capable of operation.
High maintainability
Replaceable feeder bottom plate and upturned gearbox front baffle for easy maintenance.
High efficiency
High capacity rotary feeding system for more efficient operation.
| Type | Unit | 9YF-1900C |
| Overall dimensions (L× W × H) | mm | 6647*2820*1820 |
| Total weight | kg | 1265 |
| Bale section (width × height) | mm | 360*460 |
| Bale length | mm | 300-1200 |
| Piston frequency | t/min | 92 |
| Pickup width | mm | 1930 |
| Number of pick up springing teeth/type of springing teeth | / | 156 |
| Space between spring tooth | mm | 70 |
| Feeder rake | / | Three sets of six fork teeth |
| Overload protection | / | Shear bolt |
| Cording box capacity | / | 6 rolls |
| Cord type | / | Plastic rope / Nylon rope |
| Knot-tying mechanism protection | / | Shear bolt |
| Matched power | kw/hp | 50~70kw/ (65~100hp) |
| Drive shaft speed | r/min | Min540,Max860 |
