• Model NO.：4JQH-135, 4JQH-165, 4JQH-170, 4JQH-180, 4JQH-200
• Portable Harvester Type：Backpack Type
• Certification：ISO9001:2008, CE
• Color：Red
• Condition：New
• Application Field：Agriculture, Livestock, Aquaculture, Forestry
• Weight：700kg
• Key Selling Points：High Productivity;Multifunctional
• Warranty：1 Year
• After-Sales Service Provided：Commissioning and Training, Online Support
• After Warranty Service：Video Technical Support,Online Support
• Video Outgoing-Inspection：Provided
• Used for：Harvesting Corn Sorghum Straw and Forage Grass
• Function：Harvesting,Crushing and Recycling
• Harvesting Width：1.35-2m
• Rotating Blade Quantity：32-52
• Recycling Rate：More Than80%
• Crushed Straw Length：Less Than 80mm
• Working Speed：2-4km,H
• Fling Height：More Than 2m
• Fling Distance：3-5m
• Transport Package：Standard Packing
• Specification：1.48*1.98*3.5m
• Origin：China
• Production Capacity：500 Set,Sets Per Month

Model

4JQH-135

4JQH-150

4JQH-165

4JQH-170

4JQH-180

4JQH-200

Size(m)

1.5*1.81*3.35

1.48*1.98*3.5

1.48*2.13*3.5

1.48*2.18*3.5

1.48*2.28*3.5

1.68*2.46*3.36

Weight(kg)

640

700

790

820

980

800

Capacity(hm²/h)

0.25-0.48

0.3-0.5

0.32-0.55

0.35-0.58

0.36-0.6

0.36-0.72

Harvesting width(m)

1.35

1.5

1.65

1.7

1.8

2

blade Quantity

32

40

44

44

48

52

Power(kw)

29.4-44.1

40-51

40-59

45-62

48-66

66.2-88.2

Recycling rate

≥80%

Fling distance(m)

3- 5

Fling height(m)

≥2

 crushed straw length(mm)

≤80

Stubble height(mm)

≤150

ground clearance(mm)

≥320

Cutter shaft speed(r/min)

2160

Working speed(km/h)

2-4

Application of straw silage harvester

1. Grain stalk such as corn straw, sorghum straw, and other grasses all can be the raw materials.

2. The harvested and crushed crop stalks can be directly used in farms to feed animals, feed mills to process into feed pellets. The finished products can also be used in the production of charcoal, straw coal, and other biomass power generation fuels. It can also be used as the cultivation substrate of edible fungi farmers and other industries of product processing.



The successful case of silage harvester machine

This year, our customers from Pakistan and Ecuador had ordered 10 sets of straw cutter machines with great satisfaction. He asked us for many details such as cutting width, tractor, recycling rate, etc. We aim to solve every problem our customer has and provide the best service. Influenced by patience and professional skills, he introduced our machine to his friends after receiving the machine.




Zhengzhou Shuliy machinery Co., Ltd. We not only provides customers with good quality and cost-effective products, but also provides first-class service support and solutions. Our agricultural machinery have always been very popular in Africa, South East Asia, and the North American market and have won wide praise from customers.  Perfect after-sales service system allows you to worry-free.
