• Model NO.：LQ-7600
• Transmission：Hard Shaft
• Portable Harvester Type：Side Hanging Type
• Color：Green
• Condition：New
• Application Field：Agriculture
• Warranty：One Year or 1500 Working Hours
• Engine Brand：Cummins
• Engine Model：4BTA3.9-C130
• Engine Power：130HP
• Dimension：4900*2600*3100mm
• Max Grapple Height：5400mm
• Max Dumping Height：5300mm
• Machine Weight：7600kg
• Grab Capacity：1200-1300kg
• Tire Size：23.1-26
• Transport Package：No
• Specification：LQ-7600
• Trademark：luqing
• Origin：Qingzhou, Shandong, China
• HS Code：8433510090
• Production Capacity：100 Sets for One Year

Basic Info.

Model NO. LQ-7600 Transmission Hard Shaft Portable Harvester Type Side Hanging Type Color Green Condition New Application Field Agriculture Warranty One Year or 1500 Working Hours Engine Brand Cummins Engine Model 4BTA3.9-C130 Engine Power 130HP Dimension 4900*2600*3100mm Max Grapple Height 5400mm Max Dumping Height 5300mm Machine Weight 7600kg Grab Capacity 1200-1300kg Tire Size 23.1-26 Transport Package No Specification LQ-7600 Trademark luqing Origin Qingzhou, Shandong, China HS Code 8433510090 Production Capacity 100 Sets for One Year

Product Description

Brife introduction

1. Engine: Adopt Cummins diesel engine, excellent performance, low fuel consumption,

low noise, large power reserves, long stroke

2. Oil tube: Choose high-pressure rubber pipe, which suits all bad working environment,

antiquake, anti-loose, stand fire.

3. Hydraulic working sustem: taking advanced of foreign advanced technology, it can

reduce wobble with buffer function, and the machine service life can be extended.

4. Surface treatment: derusting with large size shot blast machine, to change welding stress.

5. Surface spray coating: anti ruesting painting

6. Prepositive push piller, convenient for collection.
7. Oil return filter is set in oil return pipeline to guarantee the cleaness of hydraulic oil

Basic specifications

Max grapple height	5400mm
Max dumping height	5300mm
Max grapple radius	5300mm
Engine model	4BTA3.9-C130
Rated power	130HP
Engine brand	Cummins
Total machine weight	7600kg
Grab capacity	1200-1300kg
Working efficiency	3000kg/min
Working times	3/min
Hydraulic system working pressure	20Mpa
Maxing flux	63ml/r/63ml/r
Slope	25%
Working speed	≤30km/h
Boom rotation angle	110°
Overall dimension (L*W*H)	4900*2600*3100mm
Min. ground clearance	580mm
Wheel base	2000mm
Tires	23.1-26
Fuel consumption	≤225g/kw.h
