• Model NO.：SFSP998
• Pellet Mill Type：Ring Die Pelleter
• Bulking Machine Type：Twin Screw Bulking Machine
• Expanding Method：Wet Expansion
• Condition：New
• Applicable Materials Shape：Granular
• Warranty：1 Year
• Output(T/H)：10-50
• Power (Kw)：50-220
• Voltage：380V 50Hz
• Bearing：Imported
• Transport Package：Pallet
• Specification：CE, ISO9001
• Trademark：FDSP
• Origin：China
• HS Code：8436100000
• Production Capacity：10-50t,H

Basic Info.

Model NO. SFSP998 Pellet Mill Type Ring Die Pelleter Bulking Machine Type Twin Screw Bulking Machine Expanding Method Wet Expansion Condition New Applicable Materials Shape Granular Warranty 1 Year Output(T/H) 10-50 Power (Kw) 50-220 Voltage 380V 50Hz Bearing Imported Transport Package Pallet Specification CE, ISO9001 Trademark FDSP Origin China HS Code 8436100000 Production Capacity 10-50t/H

Product Description

SFSP Series Ruminate Animal Feed Hammer MillFeatures1. The grinding chamber is of tear circle shape, effectively eliminating the circular flow in the grinding process and getting higher capacity;
2. The Bottom of grinding chamber is fitted with U-shape double grinding structure, further improving the capacity with evener particle size;
3. Rotor passes accurate dynamic balancing test, resulting in low equipment noise and smooth running.
4. Both coarse and fine grinding is realized through adjusting the gap between beater and screen;
5. New type S shape coupling directly connecting driving results in big offset travel and effectively avoid the heating of bearing;
6. Beater blade edge is vacuum-welded by special alloy steel, resulting in long service life;
7. The imported products are used for key parts, resulting in long service life and low maintenance cost;
8. The moving full-wide operation door facilitates maintenance and replacing of beater;
9. It is widely used in various feed mills, oil plants, alcohol plants, citric acid plants, etc.
Technical Parameters of FDSP Hammer Mill

Model Parameters	SFSP998-I	SFSP998-II	SFSP998-III	SFSP998-IV
Dia. Of Rotor(mm)	1200	1200	1200	1200
Width Of Grinding Chamber(mm)	300	400	500	600
Speed Of Rotor(rpm)	1480	1480	1480	1480
Power(kw)	55/75	90/110	110/132/160	180/200/220
Output(t/h)	10-15	12-20	25-35	38-50

Pictures

FDSP is total solution provider mainly for feed industry and integrated with feed machinery, storage machinery, fertilizer machinery renewable energy machinery and its engineering. Taking "To create value for customers" as our motto, we are dedicated to provide elaborately-designed, economic & attractive, durable solution for our overseas customers.

We have passed Certificate for ISO9001, CE,SGS and our customers are enjoying with us in SEA, Middle East, Africa, Oceania, South America, etc. We have accumulated abundant experience for comprehensive development, utilization of agriculture.

We will become leader definitely for industry and strive to boost well-beings of society, be trustworthy, stable partner for long-term and create value for customers.
