• Model NO.：DZJ-I 3.0
• Power( Kw)：122kw
• Material Moisture：2%~5%
• Warranty：1 Year
• Transport Package：Wood Box
• Trademark：YUFCHINA
• Origin：Henan, China (Mainland)
• Production Capacity：150 Set,Sets Per Month

Model

DZJ-I 1.0

DZJ-I 2.0

DZJ-I 3.0

DZJ-I 4.0

DZJ-II 1.0

DZJ-II 2.0

Capacity(t/h)

1~1.5

1.5~2.5

2.0~3.0

3.0~4.0

1~2

1.5~2.5

Power( kw)

15kW

18.5kW

22kW

30kW

15kW

18.5kW

Pressure Roller Spec

Φ150×220

Φ150×300

Φ186×300

Φ300×300

Φ150×220

Φ150×300

Feed Size

≤0.5mm

≤0.5mm

≤0.5mm

≤0.5mm

≤0.5mm

≤0.5mm

Finished Product Spec

Φ2.5~Φ10

Φ2.5~Φ10

Φ2.5~Φ20

Φ2.5~Φ30

Φ2.5~Φ10

Φ2.5~Φ20

Speed Reducer Model

ZQH350

ZQH400

ZQH400

ZQH500

 special

 special

Material Moisture

2%~5%

2%~5%

2%~5%

2%~5%

2%~5%

2%~5%

Features of Double roller extrusion granulator:

1. Compact Structure, can be installation by single machine or parallel multiple machines for big capacity.

2. The granulating system is simplized for one time pressing in normal temperature, no need extral drying and cooling system, which is economic for input.

3. Roller press made by 20 CrMoTi, which is high grade material and anticorrosive.

4. Wide adaptability for raw materials, such as fertilizer, feed, chemical industry, especially good adaptability for rare earth, metallurgy, coal, biologics environmental protection.




Advantage of the granulator machine

1. roller extrusion granulator is a newly developed granulating machine in fertilizer industry.

2. It uses squeezing principle to form fertilizer particles with diameters of 2.5-20mm in one time.

3. It has higher granulating ratio of over 90%.

4. Keep the moisture between 2-5% for the raw materials is good for the roller granulator press performance.

5. Working with crusher, mixer to finish the production line which is simple design.

6. Less cost and quick granulating,thus it can bring fertilizer investment a good economic returns.

Now Contact us to get best price of Double roller extruder fertilizer granulator machine.
