Deutz-Fahr Farmlead Sh Agricultural Farm Tractor 90HP Powerful 4 Cylinder Tier II Engine Tractor
DEUTZ-FAHR MACHINERY CO., LTD.- Transport Package：Container, Sea, Train
- Specification：20CBM
- Trademark：Farmlead
- Origin：China
Base Info
- Model NO.：FL904
- HS Code：87019410
- Production Capacity：40 Per Day
Description
70/2300 kW/rpm Fuel consumption @ nominal power ≤235 Air Intake Type TC N / Displacement 4/4.578 Air filter Wet/Dry Torque reserve 41% Transmission system Clutch Single disc - Dry clutch -12" No. of gears 16F+8R:4X(2+1)X2 Shift method Sliding sleeve Max. speed 32.22km/h Gear position Command aside Hydraulic system Hydraulic output flow rate 46 Hydraulic output valve 2 slices 4 ways Working device Three-point-linkage 2 type PTO Speed PTO 540/1000 Lifting Capacity (610mm)kN 22 Tillage depth adjustment Position, Float Parameter The whole machine size (dimensions) mm 4370X2100X2760 Min. operation mass (kg) 4105(W/ cabin)/3805(W/O cabin) Mini turning Radius (m) 4.9 Rated traction force(KN) 21.8 Deck Flat Deck Wheelbase(mm) 2270 Minimum ground clearance (mm) 375 Cabin Basic:ROPS, Opt., canopy or Heating Cabin, or HVAC cabin Front/rear wheel track stepwise adjustment
Front:1610/1710/1750/1810/1850/1970(common 1610)
Rear:
1620/1720/1820/1920/2020
(common 1620)
Rear stepless adjustment
1620-2020
(common 1620) Tyre size Normal tyre:
11.2-24/16.9-34 Braking and steering Braking system Wet type,disc brake Steering type Hydraulic steering Steering Angle 43.8
Front:1610/1710/1750/1810/1850/1970(common 1610)
Rear:
1620/1720/1820/1920/2020
(common 1620)
Rear stepless adjustment
1620-2020
(common 1620)
11.2-24/16.9-34
