• Model NO.：DGP60
• Applicable Materials Shape：Flour
• Main Power：15kw
• Feeding Power：0.4kw
• Cutter Power：0.4
• Spiral Diameter：60mm
• Productivity：0.03-1.5t,H
• Size：1450X950X1430mm
• Weight：480kg
• Transport Package：Fumigation-Free Wooden Box
• Specification：1450x950x1430mm
• Origin：China
• HS Code：8436100000
• Production Capacity：50sets,Month

Basic Info.

Model NO. DGP60 Applicable Materials Shape Flour Main Power 15kw Feeding Power 0.4kw Cutter Power 0.4 Spiral Diameter 60mm Productivity 0.03-1.5t/H Size 1450X950X1430mm Weight 480kg Transport Package Fumigation-Free Wooden Box Specification 1450x950x1430mm Origin China HS Code 8436100000 Production Capacity 50sets/Month

Product Description

Pet food pellet machine is a kind of equipment used to process pellet feed. The use of feed pellet machines can reduce feed costs, reduce feed waste, and farmers can obtain higher economic benefits.

Model	Main power KW	Feeding power KW	Cutter power KW	Spiral diameter mm	Productivity t/h	Size mm	Weight kg
DGP40	4.0	0.4	0.4	40	0.03-0.04	1400x1030x1200	240
DGP50	11	0.4	0.4	50	0.06-0.08	1400x1030x1200	320
DGP60	15	0.4	0.4	60	0.12-0.15	1450x950x1430	480
DGP70	18.5	0.4	0.4	70	0.18-0.25	1600x1400x1450	600
DGP80	22/27	0.4	0.75	80	0.3-0.35	1850x1470x1500	800
DGP90	30/37	1.1	1.5	90	0.4-0.45	1900x1500x1600	1200
DGP100	37	1.1	1.5	100	0.45-50	2000x1600x1600	1500
DGP120	55	1.1	2.2	120	0.5-0.7	2200x2010x1700	1850
DGP135	75	1.1	2.2	135	0.8-1.0	2600×2200×1850	2500
DGP160	90	1.5	2.2	160	1.2-1.5	2800x2400x1850	2800

Operation steps:
1. Mix the raw materials and mix them.
2. Pour the mixed raw materials into the feed bin.
3. Turn on the cutter switch and adjust the cutter speed.
4. Adjust the distance between the cutter and the mold to control the size of the particles.
5. Turn on the host switch (green start button) to ensure the positive selection of the motor
6. Turn on the feeding switch and adjust the feeding speed. The final product pellets are obtained.
7. When the production is completed, turn off the main motor, turn off the cutter switch, and turn off the feed switch.
8. After stopping, remove the protective cover and keep the machine idling for one minute.
9. Take out the screw, clean it up, and clean up the mold for next use.

Advantage:
1. Simple structure, wide adaptability,
2. Less floor space and low noise.
3. Pellet feed is more conducive to storage.
4. Feeding animals can obtain higher economic benefits.
5. The produced feed pellets have a smooth surface and internal maturation, which can improve the digestion and absorption of nutrients.
6. The particle formation process can reduce various insects and digestive system diseases.
FAQ
A: What are the raw materials generally included, what is the humidity, and what is the fineness?
B: The main raw materials are corn meal, soybean meal, wheat bran, fish meal and the like; the humidity of the raw materials is generally between 15 and 20%, the finer the better, generally between 60 and 80.
A: Can both sink and float be made?
B: It can be done. You can make sinking feed by replacing the screw sleeve of the machine. The advantage of the feed machine for sinking feed is that the pellets can be made round or cylindrical, and the size can be adjusted at will .
A: The sleeve of the machine is 3 and 4 sections. What are the advantages? Does the sleeve here refer to the threaded sleeve?
B: The sleeve refers to the screw sleeve. The effect of the 3rd and 4th sections of the extruded fish feed is not obvious. For dog food and cat food, the advantage of the 4th section is that the amount of meat can be larger.
A: What is the moisture after drying?
B: The humidity after drying is at 4-5 points.
