• Model NO.：U25L-4
• Material：Aviation Carbon Fiber and Aviation Aluminum
• Type：Sprayer Drone
• Sprayer Type：Pump
• Usage：Agriculture
• Applicable Industry：Farms, Home Use, Epidemic Prevention
• Feature：Anti-Fall
• Production Material：Aviation Carbon Fiber and Aviation Aluminum
• Production Folding Size：1220mm*1220mm*600mm
• Max Pesticide Load：25kg
• Aircraft Medicine Box Capacity：25L
• Flight Radius：Less Than 5000m
• Max Takeoff Weight：51kg
• Aircraft Weight：16.6kg
• Flight Attitude：Less Than 30m
• Flight Duration：20-25minutes
• Condition：New
• Warranty Time：12 Months
• Transport Package：Professional Package Box
• Specification：1 CBM
• Trademark：UNID
• Origin：China
• HS Code：8802200090
• Production Capacity：10000 Unit

Basic Info.

Model NO. U25L-4 Material Aviation Carbon Fiber and Aviation Aluminum Type Sprayer Drone Sprayer Type Pump Usage Agriculture Applicable Industry Farms, Home Use, Epidemic Prevention Feature Anti-Fall Production Material Aviation Carbon Fiber and Aviation Aluminum Production Folding Size 1220mm*1220mm*600mm Max Pesticide Load 25kg Aircraft Medicine Box Capacity 25L Flight Radius Less Than 5000m Max Takeoff Weight 51kg Aircraft Weight 16.6kg Flight Attitude Less Than 30m Flight Duration 20-25minutes Condition New Warranty Time 12 Months Transport Package Professional Package Box Specification 1 CBM Trademark UNID Origin China HS Code 8802200090 Production Capacity 10000 Unit

Product Description

2021 hot sale 25l fumigation uav drone long range drone rc agricultural drone sprayer
- OEM  & ODM Service -

Model	U25L-4
Product material	Aviation carbon fiber + aviation aluminum
Product Extended size	1990mm*1990mm*600mm
Product folding size	1220mm*1220mm*600mm
Packaging size
Maximum takeoff weight	51KG
Aircraft weight	16.6KG
Aircraft medicine box capacity	25L
Flight altitude	≤30 meters
Fly time(unloaded)	20~25 minutes
Fly time(loaded)	10~13 minutes when fully loaded
Flight speed	1-10 m / sec
Structrue life span	≥10 years
Spray  width	4-8 meters
Hovering in the air	Hovering in any direction
Spray flow	3-8L/min double pump adjustable
Spray system	Imported high pressure anti-floating atomizing nozzle
Atomization point size	60~90μm
Fly control	Industrial Version GPS and Controller
Spray efficiency	≥8 hectares/hour
Motor speed	5000 rpm
Safe takeoff and landing wind speed	≤5
Power system	56V power polymer computer battery
Charger	AC Input100-240V
Lithium-polymer battery	19000mAh*1

Function
1. Automatic line-feeding spray (recyclable spraying);
2. Automatic flight spraying at point AB (plant protection aircraft can fly autonomously and record automatically after spraying);
3. Fully autonomous spraying of plots (the area and terrain of the selected plots of the ground station are determined, and the aircraft can be autonomously sprayed);
4. One-click record of medicine break point (automatically record the main point after pesticide spraying in the spraying process and return to take-off point to change medicine);
5. One-click return to the medicine break point (after spraying pesticides, the main points are automatically recorded after spraying, and then return to the take-off point to change the coloring medicine. After changing the medicine, the machine will automatically return to the medicine break-off point. spray);
The signal of the remote control antenna is best placed horizontally. (It is better to be on the left side of the rear of the drone when flying, the signal reception of the drone is better)
