Heavy Duty Rotary Tiller Cultivator Pto Drive 3 Point Linkage for Tractor

Changzhou Qianyi Machinery Technology Co., Ltd.
  • After-sales Service:Within 1 Hour
  • Type:Rotary Tiller
  • Application Field:Agriculture, Livestock, Aquaculture, Fisheries, Forestry
  • Farming Policy:Dry Cultivating Machinery
  • Power Source:Tractor
  • Operation:Soil Preparation Machinery, Movable Operation

Base Info

  • Model NO.:IGN
  • Traction Type:Hanging
  • Drive Type:Chain Drive
  • Arbor Configuration:Horizontal Axis
  • Certification:CE
  • Color:Customsized
  • Warranty:1 Year
  • Transport Package:Wooden Package or Steel Crate
  • Trademark:QianYi
  • Origin:Changzhou, China
  • Production Capacity:1000PS,1 Month

Description

Basic Info.

Model NO. IGN Traction Type Hanging Drive Type Chain Drive Arbor Configuration Horizontal Axis Certification CE Color Customsized Warranty 1 Year Transport Package Wooden Package or Steel Crate Trademark QianYi Origin Changzhou, China Production Capacity 1000PS/1 Month

Product Description

MODELIGN 90IGN 105IGN 125
Structure Weight250kg265kg285kg
Tilling Width895mm1045mm1245mm
Tilling Depth150mm150mm150mm
No. Of Blade182430
PTO Turning Speed540r/min540r/min540r/min
Tractor HP16-20hp20-28hp25-30hp

MODELIGN 135IGN 150IGN 180
Structure Weight300kg320kg350kg
Tilling Width1345mm1495mm1795mm
Tilling Depth150mm150mm150mm
No. Of Blade303642
PTO Turning Speed540r/min540r/min540r/min
Tractor HP25-30hp30-50hp40-75hp

product description: Rotary tillers manufactured by qianyi are all PTO-driven and are used to loosen and mix both firm soil, during primary tillage, and tilled soil (e.g. during secondary tillage to prepare the seed bed).
The tilling implements, which can consist of hoe, radial blade or spike assemblies mounted on a horizontal rotor (4 or 6 per flange), work by cutting and ripping clods of soil.
Rotary tiller cultivation can be performed as an alternative to plowing. It is useful in that it effectively breaks up the earth, even uprooting crop residue, and therefore generally eliminates the need for additional soil preparation.

These machines are most widely utilized in the horticulture sector and on naturally loose ground; the working depth is generally not greater than 15 cm.



our advantage:A  whole complete set of production equipment lead to  short  lead time and better prices of machine.

Guarantee one year warranty of all our products.

Produce machines according to any requirements from our customers.

New machines will be developed  every year.


Every model of our machine will be tested before the delivery to the port.

If you want to visit our factory, our boss will give you a best reception.
