CE ISO Hot Sale 3-14 T/H Feed Pellet Press Machine with High Output

Jiangsu Liangyou Zhengda Co., Ltd.
  • After-sales Service：Provided
  • Type：Pellet Mill
  • Processing Object：Animal-Derived Feed
  • Processing Technics：Crushing-before-Mixing
  • Screen Mesh：With Screen Mesh
  • Grinding Equipment Type：Feed Hammer Mill

Base Info

  • Model NO.：SZLH420
  • Pellet Mill Type：Ring Die Pelleter
  • Bulking Machine Type：Twin Screw Bulking Machine
  • Expanding Method：Wet Expansion
  • Condition：New
  • Applicable Materials Shape：Powder
  • Warranty：1 Years
  • Brand Name：Fdsp
  • Motor Brand：Siemens
  • Bearing Brand：SKF,NSK
  • Pellet Size：2-18mm
  • After-Sales Service Provided：Engineers Available to Service Machinery Overseas
  • Transport Package：Pallet
  • Specification：1000KG
  • Trademark：FDSP
  • Origin：Jiangsu China
  • HS Code：8436100000
  • Production Capacity：3-12t,H, 3-14t,H

Description

Basic Info.

Model NO. SZLH420 Pellet Mill Type Ring Die Pelleter Bulking Machine Type Twin Screw Bulking Machine Expanding Method Wet Expansion Condition New Applicable Materials Shape Powder Warranty 1 Years Brand Name Fdsp Motor Brand Siemens Bearing Brand SKF/NSK Pellet Size 2-18mm After-Sales Service Provided Engineers Available to Service Machinery Overseas Transport Package Pallet Specification 1000KG Trademark FDSP Origin Jiangsu China HS Code 8436100000 Production Capacity 3-12t/H, 3-14t/H

Product Description

CE ISO Hot Sale 3-14 t/h Feed Pellet Press Machine With High Output
 Features
1. Gear directly-connecting driving is adopted for high efficiency;
2. Full stainless steel feeder; Variable pitch anti-bridging structure; Imported FC control;
3. All stainless steel conditioner with axial steam spraying extends the conditioning and cooking time;
4. Main gear and pinion shaft adopt the carbonizing quenching with high accuracy; Smooth driving, low noise and long service life;
5. Gearbox and driving holes' accuracy are guaranteed by specialized casting supplier and NCC;
6. The bearing and oil seal in the main drive are imported, and especially lubrication oil return system is available to ensure reliable bearing lubrication;
7.2 pc quick disassembling type precisely-cast die clamp is adopted to connect the die and quill flange, resulting in convenient and quick disassembling of die;
8. Pellet chamber door and feed chute are fully made of stainless steel with high anti-corrosion ability and long service life;
9. The connection between motor and gearbox adopts new type S-shape spring coupling with more convenient disassembling and assembling and more reliable use.
     Parameters ModelOutput (t/h)Main Power(kw)Power of Conditioner (kw)Power of Feeder (kw)ID of Die (mm)Pellet Size (mm)
   SZLH400b1   3-12   75/90      5.5      1.5       400    2-18
   SZLH420b1   3-14   90/110    5.5       1.5      420    2-18
