• Model NO.：PM-150
• Power Source：Diesel Engine & Motor
• Material：Carbon Steel
• Power：4 Kw
• Certificate：ISO9001,Ce
• Weight：100kg
• Diameter：2-10mm
• Transport Package：Export Standard Packing by Wooden Case
• Specification：90-120 kg,h
• Trademark：YUFCHINA
• Origin：China
• HS Code：8474802000
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. PM-150 Power Source Diesel Engine & Motor Material Carbon Steel Power 4 Kw Certificate ISO9001/Ce Weight 100kg Diameter 2-10mm Transport Package Export Standard Packing by Wooden Case Specification 90-120 kg/h Trademark YUFCHINA Origin China HS Code 8474802000 Production Capacity 100 Sets Per Month

Product Description

120kg capacity small scale feed pellet mill


Advantage and disadvantages of small scale feed pellet mill

Advantage:

1. Small in size and light in weight

2. Easy to clean and maintenance

3. Cheap in price


Disadvantages:

Not suitable for scale production.


       In the small and medium scale pellet plant, flat die pellet mills are the ideal choice for both fuel pellets and feed pellets producing. Comparing with ring die pellet mill, flat die pellet machine is good at energy-saving, small area needed and low cost.



Electric Flat die feed pellet mill:

Introduction of Poultry Feed Pellet Mill

      Poultry feed and livestock feed are very important for breeding industry.

but it is also troublesome to mix feed for the poultry every day. With the introduction of electric poultry feed pellet mill, we can easily make powder feed into feed pellets. Our electric poultry feed pelletizer is specially designed for small poultry farm or home use.

driven by electricity, small body, light in weight and simple operation. Most important, the feed pellets produced by this electric poultry feed pelletizer have rich nutrition, good palatability and high digestibility.

Features of Electrical Feed Pellet Mill

1. Driving by Electric motors.

2. No need any binder for pellet making.

3. Change the die to get different size of pellet.

4. Kill all the parastic ovum and other pathogenic while pelletizing by the high temperature and pressure.

5. Less energy with competitive price.





Application of Poultry Feed Pellet Mill

        Suitable for processing various kinds of solid grain into small feed pellets for poultry like chicken, duck, geese, quail and livestock including cattle, cow, rabbit, pig, etc.

The raw materials are easy to obtain, like corn, maize, wheat bran, rice, beans, etc.

Electric poultry feed pellet mill is popular with small feed pellet plant, breeding farm, and poultry farm.

Why Choose Poultry Feed Pellet Mill for Your Chicken?

       This poultry feed pelletizer for small poultry farm or home use is different from other feed pellet mills. As for chicken, they are kept for fast and health growth. The feed of chicken should emphasize the nutrition content and ingredients. We developed this homemade chicken feed pelletizer and focused to increase the integrity of nutrition and palatability which can accelerate chicken to have more than usual. What's more, chicken in different growing stages need different size feed pellets, with this machine, you can make feed pellets from 2-10 mm, which meets different needs.


Technical parameters of flat die feed pellet machine


Model	Power	capacity for feed (kg/h)	capacity for biomass (kg/h)	Driving Transmission
PM-120	3kw (3phase) /2.2 kw (Single phase)	60-100	40-80	motor
PM-150	4 kw (3phase)	90-120	50-100	motor
PM-200	7.5 kw (3phase)	200-300	80-120	motor
PM-230	11 kw (3phase)	300-400	120-200	motor
PM-260	15 kw (3phase)	400-600	160-250	motor
PM-300	22 kw (3phase)	600-800	250-320	motor
PM-400	30 kw (3phase)	900-1100	400-450	motor
PM-500	55 kw (3phase)	1200-1500	800-1000	motor
PM-120	8 Hp	60-100	40-80	diesel engine
PM-150	8 Hp	90-120	50-100	diesel engine
PM-200	15 Hp	200-300	80-120	diesel engine
PM-230	22 Hp	300-400	120-200	diesel engine
PM-260	35 Hp	400-600	160-250	diesel engine
PM-300	55 Hp	600-800	250-350	diesel engine
PM-400	55 Hp	900-1100	400-450	diesel engine
