Mini Farm Crawler Tractor for Rice Paddy Filed and Dry Land
Wuxi Rafiki Tools Co., Ltd.- Type：Micro-Farming Machine
- Application Field：Agriculture
- Farming Policy：Paddy Field Machinery
- Power Source：Tractor
- Operation：Soil Preparation Machinery, Continuous Running Operation
- Traction Type：Traction
Base Info
- Model NO.：RAFIKI-752
- Arbor Configuration：Horizontal Axis
- Color：Green
- Warranty：1 Year
- Weight：1860kg
- Minimum Ground Clearance：450mm
- Crawler：90*52*350
- Transport Package：No Packing
- Specification：3120X1660X2370mm
- Trademark：VOWO
- Origin：Jangsu China
- HS Code：8701300010
- Production Capacity：30PCS
Description
MINIMUM WEIGHT (KG):1860
MINI GROUND CLEARANCE (MM):450
CRAWLER (PITCH×PCS×WIDTH):90×52×350
TRACK (MM):1200
FUEL TANK CAPACITY (L):78
ENGINE SUPPLIER:KUNMING YUNNEI
ENGINE MODEL:YN4EZ075-31CR
START MODE:ELECTRIC
INTAKE TYPE:TURBOCHARGING
RATED POWER (KW):55
RATED SPEED (r/min):2600
TRANSMISSION SYSTEM:(3/3)HST CVT
BRAKE TYPE:MULTI-CHIP
POWER OUTPUT SHAFT FORM:NON-STAND-ALONE
PTO SHAFT SPEED(r/min):540/720
STEERING TYP:HST
STEERING CONTROL MECHANISM:CONTROL LEVER
POSTPOSITON SUSPENSION TYPE:SEMI-SPLIT TYPE II SUSPENSION
Working condition:
Our crawler tractor used hydraulic continuously variable speed travel, which is used for rotary tillage or intensive tillage on uncultivated land and cultivated land. It is widely used in rice, wheat, sugarcane, rapeseed and other production areas of water and dry land farming and broken roots back to the field for farming. It has finely crushed soil blocks for dry land cultivation, sufficient muddy mud for paddy field cultivation, flat surface after cultivation, good weed stubble coverage, moderate tillage depth, not easy to sink, high working efficiency, one working can reach the effect of multiple plough and rakes. At the same time, it has its strong anti-sag performance. It does not damage the field foundation (plowing the ground) during paddy field operation, which greatly protects the soil, soil quality and environment. Therefore, it is also very suitable for shallow farming in lake areas, salt and alkali soils, and The role of inhibiting the rise of salt, as well as the intensive cultivation of vegetable and tobacco fields, etc., its rotary tillage performance, ridge and furrowing performance
Our Advantage:
1. continuously variable speed,easy and convenient operation.
2. Wide track, high ground clearance, especially suitable for paddy field operations.
3. Suspension frame double-cylinder jacking system, the hydraulic system is more stable.
4. Flexible matching of working parts, simultaneous operation of fertilization and rotary tillage.
