• Model NO.：BX92R
• Production Capacity：1000PS,1 Month

Basic Info.

Model NO. BX92R Production Capacity 1000PS/1 Month

Product Description

Model	BX92RS
Chipper Capacity	250mm/10''
Chipper Housing Opening	10''x15''
No.of Knives	4
Rotor Size	36''
Feeding System Feed	Hydraulic Feed
Hopper Folded	66''Lx68''Wx90''H
Hopper Opening	25''x25''
Mounting System	3 Point Hitch
Discharge Hood Rotation	360˚
Discharge Hood Height	90''
Structure Weight	625kg
Tractor HP	70-120hp


our description :The  BX92RS Hydraulic PTO Wood Chipper has a 9″ chipper capacity and a 10.5″ x 14″ chipper housing opening and is fitted with a 125kg heavyweight Rotor.  This model Wood Chipper has a direct hydraulic feed from the tractor hydraulic rear connection plugs.
Direct PTO drive that operates as a fix drive system and without the use of gears and belt drives and this model is fitted standard with easily replaceable blades by removing 3 removable bolt for simple and easy access to the top half of housing and the hopper can also be fully opened with 2 removable bolts.
This model Wood Chipper has a full hydraulic feed system that allows for fast, medium or slow flow rate settings and with its 3 feed setting options from feed direction of forward, reverse and neutral settings.
The Hydraulic model allows for consistent chipping as the Hydraulic System has double support arms from both sides of the internal hopper with drive force from its hydraulic motor and with a Dual Barrel System that enables dragging motion for consistent cutting.
The Hydraulic Feed Chipper model is a simple and low maintenance chipper and able to handle the hardest and knotted wood. our advantage:A  whole complete set of production equipment lead to  short  lead time and better prices of machine.

Guarantee one year warranty of all our products.

Produce machines according to any requirements from our customers.

New machines will be developed  every year.

Every model of our machine will be tested before the delivery to the port.

If you want to visit our factory, our boss will give you a best reception.
