• Model NO.：TS-35A
• Power Supply：Electric
• Technics：Self-Adhesive Label
• Material：PE
• Type：Aligning Sprayer
• Name：Ulv Thermal Fogger
• Repeatability：0.3%
• Storage Temperature Rating：- 40 ~ + 70 ºC
• Operating Voltage：220VAC ± 10% 50Hz Continuous Working H
• Internal Pump Fast Response Time：Only 1 Second
• Relative Humidity：≤90%Rh
• Transport Package：Wooden Box with Foam Inside
• Specification：CE,ISO,IEC
• Trademark：Huazheng
• Origin：Hebei, China
• HS Code：9027100090
• Production Capacity：500,Month

b) Fuels or white oils

Nebal

3.0L

Vegetable Oil

2.5L

Glyzerine

2.5L

Diesel or Heating Oil

2.0L

Ekomist

2.0L

Kerosene

2.0L

Ethylengkole

2.0L

Petropal

2.0L

UK2-spezial

2.0L

Shell Risella

1.5L

VK1

1.5L





Nevolin or nevocol

1.5L





Note: The special carrier's volume must be calculated accurately according to room's volume.

Set spraying solution output, could use water to measure solution output,

Nozzle diameter(mm)

0.8

1.0

1.2

1.4

1.6

2.0

Solution output (L/h)

10

15

20

30

35

42

Note: We have installed 1.2mm diameter nozzle to machine, put 1 pcs 0.8mm and 1pcs 1.6mm diameter nozzle into standard spare parts tool kits.

Because chemicals solution viscosity and environment condition, such as temperature, pressure may influence solution output, so we recommend you to measure via your best method.



TECHNICAL SPECIFICATION



Performance of combustion chamber, approx.

18.6 KW/25.2HP

Fuel consumption , approx.

1.5 L/H

Fuel tank capacity

1.5 L

Solution tank capacity

5 L

Pressure in solution tank, approx.

0.25 bar

Pressure in fuel tank, approx.

0.06 bar

Batteries

4×1.5V

Solution output, approx.

8-42 L/H

Weight(empty), approx.

8.2 kg

Dimensions (L×W×H mm)

1370×270×315

1. The aforesaid technical specification may change when working under different altitudes and temperature condition.

2. Please use #90 gasoline, or any other type regular gasoline or petrol will be ok.
