• Model NO.：ZSDH300
• Anaesthetic Voltage：70-110V
• Mbient Temperature：-10ºC~+40ºC
• Material Quality：Galvanization
• Specification：7430*1100*1750mm
• Trademark：Jianhua
• Origin：Shangdong Qingdao
• HS Code：8438500000
• Production Capacity：2500-3000 Pieces,Day

Fault phenomenonPossible causeOverhaul method Do not work after turning on the power supply, no indication of work indicator1. The power supply is not on or in bad contact 2. The circuit breaker in the control box is not closed 3. Fuse damage of controller 1. Connect the power supply, deal with the bad part 2. Close the circuit breaker 3. Find the cause, replace the mental fuse. No automatic operation 1. The automatic working switch is not on or out of order 2. Sensor lines or not well connected. Sensor adjusting distance is too close 1. Overhaul or replace automatic switch 2. Reconnect line 3 according to wiring diagram. Readjusting the effective distance of the sensor To keep repeating empty movements1. Sensor wiring error 2. Manual start button bad 1. Readjust sensor effective range 2. Reconnect line 3 according to wiring diagram. Replace maintenance manual start buttonElectric electrodes or electric trolleys can not work1. The pressure is too low by two. Solenoid valve has no voltage (220v) 3. Mechanical moving parts jammed or rusted to death 1. Adjust the gas pressure 2. Check solenoid valve coil and connection line 3. Repair or replacement of faulty parts No voltage output during electric shock 1. The hemp switch was not turned on. The electric voltage in the control box is not adjusted 3. Electric shock plate connection line broken 1. Turn on the electric switch 2. Recalibrate the electric voltage of the anesthesia 3. Reconnect the plate circuitManual failure to work1. Manual start button damaged 2. Stop button damaged 3. Damage to control button of electric trolley 1. Replace or maintain start button 2. Replace or repair stop button 3. Replacement or maintenance of car control buttons Transmission non-rotation1. The frequency converter is not turned on or the switch is out of order 2. Frequency converter is not set 3. Frequency converter failure1. Replace switch 2. Reset 3 with reference to Inverter instruction. Replacement of maintenance frequency converter If the above method can not solve the problem, please do not blindly remove, lest the scope of the fault expanded, please contact the technical department of the manufacturer repair.
