• Model NO.：BG
• Specification：1470*1550*970
• Trademark：BG
• Origin：China
• HS Code：8465960000
• Production Capacity：500 Sets , Per Month

Basic Info.

Model NO. BG Specification 1470*1550*970 Trademark BG Origin China HS Code 8465960000 Production Capacity 500 Sets / Per Month

Product Description

wood chipper
Technical Data Sheet:


Model	BG-215	BG-216	BG-218	BG-2113
Imported materials and dimensions (mm)	160*400	230*500	300*680	450*700
Flying the number of	2	2	2	2
Knife roll speed	592	590	650	500
Maximum diameter of the processing of raw materials(mm)	160	230	300	450
Chip size (mm)	30	30	30	38
Production capacity(tons/h)	8-10	15-20	30-35	45-50
Power of main motor(kw)	45	55	110	200-250
Feed roller motor power (kw)	2.2-3	3-4	4-5	7.5*2
Pump motor power(kw)	1.5*1	1.5*1	1.5*1	3*1
Weight(kg)	2990	4070	7000	11840
Overall dimensions(mm)	1470*1550*970	1800*1900*1210	2200*2150*1500	3670*2517*2050
Electrical power transmission machine(kw)	3	3	3	3


Introduction:

It is the special equipment of producing chips.It is widely applied in particleboard factory, and the high density fiberboard, stubble, biomass power plant, wood factory industries before production units.This machine is designed for cutting machine, grinder machine designed with high precision, simple operation, easy to use, can grind various types of cutting machine, screw machine.

Features:

Hydraulic system: From the pump to oil cylinders, the cover can be opened, it is easy to change the blade. It can
    raise the upper feed roller in maintenance, it is easy to adjust the space between fly cutter and knife.
Two or three knives are installed on knife roller with specialized in manufacturing, the fly cutter is fixed on the knife roller through the bolt. According to the different thickness of raw materials by cutting, feed roller assembly by
    hydraulic system can fluctuate within a certain scope. Cutting down the qualified materials through the screen mesh
    from bottom of large discharge will cutting again in the inner of this machine.
