Tractor Mounted 800L Boom Sprayer for Agricultural, Self Propelled Sprayer
Jinan Alfing Machinery Co., Ltd.- Liquid Contained：Medicine, Disinfector
- Spraying Shape：Full Cone
Base Info
- Model NO.：200L,300L,400L,500L,600L,800L,1000L
- Volume：800L, 1000L,1200L
- Power Supply：Pressure
- Technics：Blow Moulding
- Material：PVC
- Type：Push Sprayer
- Working Width：6-12m
- Matching Power：15-100HP Tractor
- Color：Customized
- Transport Package：Iron Shelf
- Specification：800L, 1000L,1200L
- Trademark：OEM
- Origin：Shandong, China
- Production Capacity：100000 Units, Year
Description
Basic Info.
Model NO. 200L/300L/400L/500L/600L/800L/1000L Volume 800L/ 1000L/1200L Power Supply Pressure Technics Blow Moulding Material PVC Type Push Sprayer Working Width 6-12m Matching Power 15-100HP Tractor Color Customized Transport Package Iron Shelf Specification 800L/ 1000L/1200L Trademark OEM Origin Shandong, China Production Capacity 100000 Units/ YearProduct Description
Introduction of 3W series pensile sprayer:
1. The 3W series pensile spray-bar spray-spraying machine is a new type of spray-spraying machine with three points suspended behind the tractor.The sprayer is flexible in use and simple in operation, and is suitable for spraying chemical herbicide, insecticide and leaf surface fertilizer on various dryland crops.Widely used in soybean, wheat, rice, cotton, potato and other crops as well as forage grass, garden flowers and other plants pre-sowing soil treatment, seedling period of grass, and pest control.
2. Special anticorrosive materials are used in the potion pipeline with excellent corrosion resistance.The liquid pump USES the double cylinder diaphragm pump, the working pressure is stable, the spray is even.The height of spray rod is adjustable.Spray parts are equipped with drip proof nozzle to avoid leakage of residual liquid in pipeline.
Technical parameters:
| Model | 3W-200-6 | 3W-300-6 | 3W-400-6 | 3W-400-8 | 3W-500-10 | 3W-650-10 | 3W-1000-10 | 3W-500-12 | 3W-650-12 | 3W-1000- 12 | 3W-1000-14 |
| Medicine chest volume (liter) | 200 | 300 | 400 | 400 | 500 | 650 | 1000 | 500 | 650 | 1000 | 1000 |
| Spray amplitude (m) | 6 | 6 | 6 | 8 | 10 | 10 | 10 | 12 | 12 | 12 | 14 |
| Nozzle arm | 3 | 3 | 3 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 7 |
| Nozzles number (PCS) | 13 | 13 | 13 | 17 | 21 | 21 | 21 | 25 | 25 | 25 | 29 |
| Input shaft speed (RPM) | 540 | 540 | 540 | 540 | 540 | 540 | 540 | 540 | 540 | 540 | 540 |
| Rated spray pressure (kg/cm 2) | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 | 25~45 |
| Liquid pump flow rate (l/min) | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 | 30~100 |
| Working efficiency (ha/h) | 4.2 | 4.2 | 4.2 | 5.6 | 7 | 7 | 7 | 8.4 | 8.4 | 8.4 | 9.8 |
| Supporting power (horsepower) | 15~30 | 20~40 | 20~40 | 20~40 | 25~50 | 65~80 | 70~100 | 25~50 | 65~80 | 70~100 | 70~100 |
