• Model NO.：HC-WB-EC
• Warranty：12 Months
• Rated Capacity：2t~7t
• Rated Output：0.9±0.1mv,V
• Non-Linearity：±0.1% F.S
• Creep Error (30min)：±0.1%F.S
• Zero Balance：±2%F.S
• Temperature Effect on Zero：±0.05%F.S,10ºC
• Temperature Effect on Output：±0.05%F.S,10ºC
• Input Resistance：400±20Ω
• Output Resistance：352±3Ω
• Operating Temperature Range：-30~+70ºC
• Compensated Temperature Range：-10~+40ºC
• Insulation Resistance：5000mΩ
• Safe Overload：150%F.S
• Breaking Overload：500%F.S
• Recommend Excitation：5~12VDC
• Transport Package：Foam and Carton
• Trademark：HeChang
• Origin：Ningbo, China
• HS Code：9031809090
• Production Capacity：500PCS,Day

0.1%F.SCompany Profile

1. How to place an order for products?
Let us know your requirement or application, we will give you a quotation in 4 hours. After drawing confirmed, we will send you PI.

2. Do you have any minimum order quantity limit for load cell?
No MOQ required. In the mass production, unit price depends on the rough idea of Qty., the more the better.

3. Do your company have any certificate for products?
Yes, we have been awarded certifications, such as NTEP, OIML, CE. We can send you the certificated documents and test reports.

4. What areas can your products be applied to?
Our products are mainly used for weighing scales, tank weighing, force measuremnts, agriculture equipments, vehicle weighing systems, port machines, industrial process control systems and so on.

5. Can you supply customized services?
Yes, we suppliy customized services. Please don't hesitate to contact us!
