Agricultural Machinery

2021 New GPS Agriculture Usage New Condition Reliable China Uav 30L Capacity Drone Sprayer Price

Qingdao Zhongfei Intelligent Technology Co., Ltd.
  • Installation:No Installation
  • Liquid Contained:Medicine
  • Spraying Shape:Full Cone
  • Volume:16L~30L
  • Power Supply:Electric
  • Technics:Assembly

Base Info

  • Model NO.:D30L-8
  • Material:Aviation Carbon Fiber and Aviation Aluminum
  • Type:Sprayer Drone
  • Sprayer Type:Pump
  • Usage:Agriculture
  • Applicable Industry:Farms,Home Use,Epidemic Prevention
  • Feature:Anti-Fall
  • Production Material:Aviation Carbon Fiber and Aviation Aluminum
  • Production Folding Size:730mm*830mm*1560mm
  • Max Pesticide Load:25kg
  • Aircraft Medicine Box Capacity:30L
  • Flight Radius:Less Than 5000m
  • Max Takeoff Weight:75kg
  • Aircraft Weight:20kg
  • Flight Attitude:Less Than 30m
  • Flight Duration:13-40minutes
  • Condition:New
  • Warranty Time:12 Months
  • Transport Package:Professional Package Box
  • Specification:1 CBM
  • Trademark:UNID
  • Origin:China
  • HS Code:8802200090
  • Production Capacity:10000 Unit

Description

Basic Info.

Model NO. D30L-8 Material Aviation Carbon Fiber and Aviation Aluminum Type Sprayer Drone Sprayer Type Pump Usage Agriculture Applicable Industry Farms,Home Use,Epidemic Prevention Feature Anti-Fall Production Material Aviation Carbon Fiber and Aviation Aluminum Production Folding Size 730mm*830mm*1560mm Max Pesticide Load 25kg Aircraft Medicine Box Capacity 30L Flight Radius Less Than 5000m Max Takeoff Weight 75kg Aircraft Weight 20kg Flight Attitude Less Than 30m Flight Duration 13-40minutes Condition New Warranty Time 12 Months Transport Package Professional Package Box Specification 1 CBM Trademark UNID Origin China HS Code 8802200090 Production Capacity 10000 Unit

Product Description

2021 new gps agriculture usage new condition reliable china uav 30l capacity drone sprayer price
- OEM  & ODM Service -The capacity is increased to 30kg and the flight time reaches 25 minutes in no-load mode.In payload mode, it travels at 10 meters per second.Spray at a rate of 10L/min.The control system adopts agricultural professional controller, the specialized system provides excellent performance support.Can be selected with fertilizer kit, a machine multi-purpose, reduce the cost of use.
The performance of the whole machine is optimized, and the hidden circuit is designed to prolong the service life of components and reduce after-sales problems.

 Model D30L-8
 Product material Aviation carbon fiber + aviation aluminum
 Product expansion size 3090mm*3090mm*910mm
 Product folding size 900mm*730mm*1760mm
 Packaging size 1730mm*1200mm*790mm
 Maximum takeoff weight 75KG
 Aircraft weight 20-21KG
Pesticide Barrel 30L
Flight altitude ≤30 meters
Fly time(unloaded) 20~30 minutes
Fly time(loaded) 1-10 m / sec
 Flight speed ≥10 years
 Structure lift span 6-12 meters
 Spray width 10~13minutes when fully loaded
 Hovering in the air Hovering in any direction
 Spray flow 8-10L/min
 Spray system Imported high pressure anti-floating atomizing nozzle
 Atomization point size 60~90μm
 Fly control Agricultural special controller
 Spray efficiency ≥12hectares / hour
 Safe takeoff and landing wind speed ≤5
Motor speed 5000rpm
Power system48V power polymer computer battery
Charer AC Input 100-240V
Lithium-polymer battery16000mAh*2
