Agricultural Machinery

Home > Product > Agricultural Sprayers

Agricultural Machinery Self Propelled Pesticide Farm Power Agriculture Motorized Crop Boom Sprayer

Fujin Lixing Plant Protection Machinery Manufacturing Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Installation：Quick Connection
  • Liquid Contained：Pesticide
  • Spraying Shape：Sector
  • Volume：2080L

Base Info

  • Model NO.：3WPZ-2400G
  • Power Supply：Pto Shaft
  • Type：Self Propelled Boom Sprayer
  • Weight：5033kg
  • Spray Angle：110°
  • Nozzle Model：No.3
  • Transport Package：Standard Package for Export
  • Specification：6300mm x 3100mm x 3700mm
  • Trademark：LIXING
  • Origin：Heilongjiang
  • HS Code：8424490000
  • Production Capacity：200

Description

 Model 3WPZ-2400G Pump Type Plunger pump Mngine Model 4L88 (Changchai) turbocharged   diesel  engine Pump Model OS-5200 Power / Speed 73 hp      2400r / min Pump Pressure 0-45kgf/cm² Displacement Level China III Pump Flow 200-240L / min Gear Forward gear 4,reverse gear 1 Pump Speed 600-800r / min Drive Model Four-wheel drive Tank Capacity 2400L Steering Model Hydraulic steering Spray Height 0.5-3.0 m(customizable) Mixing Method Circulating water mixing Nozzle Model No.3 Folding Method Hydraulic folding Spray Angle 110 ° Spray Width 18 m Nozzle Flow 1.2L / min Vertical Height 1.9 m(customizable) System Work Pressure 0.3-0.5Mpa Wheel Track 2.2-2.8m(customizable) 3 Filtration System Tank inlet, pump inlet, nozzle Operating Efficiency 36-46 acres / hour Battery 12v / 120AH Walking Speed ≤ 30Km / h Front Tire Model Tractor tires 9.5-32 Overall Dimension 6300 mm x 3100 mm x 3700 mm Rear Tire Model Tractor tires 9.5-32 Weight 5033Kg Water Tank 15L

Agricultural Machinery Self Propelled Pesticide Farm Power Agriculture Motorized Crop Boom SprayerAgricultural Machinery Self Propelled Pesticide Farm Power Agriculture Motorized Crop Boom SprayerAgricultural Machinery Self Propelled Pesticide Farm Power Agriculture Motorized Crop Boom Sprayer
Agricultural Machinery Self Propelled Pesticide Farm Power Agriculture Motorized Crop Boom Sprayer
Q:Are you a factory or trading company?

A:We are a factory.

Q: How does your factory do regarding quality control?

A: Quality is priority. we  always say great importance to quality controlling from the very beginning to the very end.

Q: Do you have a product accessory?

A: Yes, we have all the accessories of the product.

Q:Can you customize the product?

A:We can customize the product .

Q: What's your payment terms?

A: Payment terms is T/T or L/C,We accept all reasonable payment.

Q: How about delivery time of your machine?

A: The delivery time is in 60 working days. It depending your quantity.
