• Model NO.：WSB series
• Bulking Machine Type：Sigle Screw Bulking Machine
• Expanding Method：Wet Expansion
• Condition：New
• Applicable Materials Shape：Powder
• Capacity：200 Sets Per Month
• Key Word 1：Feed Pellet Machine
• Key Word 2：Flat Die Feed Pellet Machine
• Key Word 3：Animal Feed Machine
• Pellet Size：1-12mm
• Transport Package：Wooden Cases
• Specification：ce co ccc
• Trademark：GMEC
• Origin：Henna
• HS Code：8474802000
• Production Capacity：75-1100kg H

Basic Info.

Model NO. WSB series Bulking Machine Type Sigle Screw Bulking Machine Expanding Method Wet Expansion Condition New Applicable Materials Shape Powder Capacity 200 Sets Per Month Key Word 1 Feed Pellet Machine Key Word 2 Flat Die Feed Pellet Machine Key Word 3 Animal Feed Machine Pellet Size 1-12mm Transport Package Wooden Cases Specification ce co ccc Trademark GMEC Origin Henna HS Code 8474802000 Production Capacity 75-1100kgH

Product Description

Popular flat die wood feed pellet mill pellet machine


This serious of wood pellet machine are mainly used for making the wood pellets applies for raw material like wood waste or agricultural waste, such as corn/wheat/rice straw, coffee/peanut shell, etc. The pellets are used as fuels in electricity-generating and water -heating in power plant industry, boiler factories, etc.
They adopt the imperative feeding device, reinforced conveyed parts, dedicated ring die, compression roller and hoop.

Flat Die Wood Pellet Machine
Originally designed to make feed pellets, flat die pellet mill was popular in early years. Taking customers feedback and energy market into consideration, we have absorbed the technique and brought it into wood pelletizing field. For the users who just want to recycle their agricultural waste such as corn stalk, rice husk, wheat bran,etc, investment in flat die wood pellet mill is a desirable and wise choice.
Flat Die Wood Pellet Machine Process
Wood pellets are produced by compressing the biomass material which is first grinded to provide a uniform dough-like mass. Then the mass is fed to a pelletizing chamber and formed pellets through a die with holes of the required size. The high pressure of the press makes the temperature of the wood increase greatly and the lignin slightly forms a natural "glue" which is a substance that holds the pellet together. The size of pellets is generally kept to be about 6mm diameter and 25mm length in the form of a cylinder. Of course, we can customize dies with different die holes.
Flat Die Wood Pellet Machine Features
1. The pellet mill is made of wear-resistant material thus having a long service life.
2. Ready-to-get raw materiasl like paddy straw, sunflower stalk, forestry wastes, wood chips, and many other wastes or solid powder material.
3. Able to change new die and rollers fast and conveniently.
4. Small and light weight which make it widely used in home,small farm,and light industrial.
5.Visibility of the material during pelleting is the best way to fix problems timely.
6. Environmental friendly; energy-saving and low noise.
7.  Widely applied to small-sized factory, plant and individual home.

Product Description of the Flat Die Animal Feed Pellet Machine Sawdust Pellet Machine (WSB)

1. The raw material for this machine can be the food grain like corn, wheat(do not need crush) and the crushed waste from agriculture for example, corn straw, groundnut shell, grass, wheat bran, sawdust, and animal manure and so on.

2. They can be pressed into fertilizer, fuel feedstuffs for many kinds of animals. The diameter of the pellet can be 2-12 mm.

3. When processing, the lower temperature can maintain the nutrition of the products. And through general extrusion, it can kill micro-organisms, parasites to prevent disease and to store it easily.

Type	Power	Weight(kg)	Packing  size  (mm)	Output	finished  product  size
WSB -120A	8hp	120/140	870*440*730	75-100	4-6mm
WSB -120B	3KW	80/100	750*320*510	75-100	4-6mm
WSB -120BI	2.2KW	80/100	800*300*600	75-100	4-6mm
WSB -150A	8hp	160/200	1100*500*950	100-200	4-6mm
WSB -150B	4KW	95/115	750*350*650	100-200	4-6mm
WSB -200A	15hp	240/270	1200*600*1000	200-300	4-8mm
WSB -200B	7.5KW	240/270	1000*430*950	200-300	4-8mm
WSB -230A	22hp	280/310	1180*580*880	300-400	4-8mm
WSB -230B	11KW	290/320	1140*470*970	300-400	4-8mm
WSB -260	15KW	330/380	1200*500*1070	400-600	4-8mm
WSB -300	22KW	410/450	1250*520*1070	700-800	4-10mm
WSB -360	22kw	470/500	1270*520*1070	800-900	4-10mm
WSB -400	30kw	630/660	1470*600*1150	900-1100	4-10mm
