• Material：PE
• Type：Knapsack

Nominal Voltage12VNominal Capacity8Ah or 12ah Impedance
(Max. at1000Hz)≤30mΩExpected Cycle Life2000 times

 Mechanical CharacteristicsHeight80±2mmWidth100±2mmLength100±2mmWeight~2.0Kg

 Operation ConditionsCharge MethodConstant Current/Constant Voltage
(CC-CV)Max. Charge Voltage12.6VStandard Charge Current2ACharge Temperature0ºC~45ºCMax. Continuous Discharge Current40APeak Instant               Discharge Current80A,Peak Instant               Discharge Time5 secondsDischarge Cut-off Voltage10.0VDischarge Temperature-20ºC~65ºCStorage Temperature-20ºC~45ºC

Advantages:

l  Attractive cycle life
l  Extended safety performance
l  Wide operating temperature range
l  Unrivalled high temperature performance
l  Green energy without metal contaminant
l  High capacity
l  Steady output voltage
l  Little self-discharge
l  Double safety protection
l  Withstanding very high level of vibrations and shocks

Safety Characteristics

l  Over-charge/Over-discharge Ability to withstand over-charge/withstand over-discharge, and there is no fire, no exploding and work well
l  Short circuit Ability to withstand short circuit, and there is no fire, no exploding
l  Acupuncture Ability to withstand nail puncturing, and there is no fire, no exploding
l  Thermal shock Ability to withstand thermal shock, and there is no fire, no exploding
