• Model NO.：4YZ-4
• Harvest method：Picking
• Drive Type：Gear Drive
• Transmission：Hard Shaft
• Certification：ISO9001:2008
• Color：Red
• Condition：New
• Application Field：Agriculture
• After-Sales Severice Provided：Engineers Available to Service Overseas
• Weight：5010 Kg
• Function：Picker+Thresher+Crushing
• Transport Package：Naked
• Specification：6010*2590*3320mm
• Trademark：CHMC
• Origin：Henan, China
• HS Code：8433510090
• Production Capacity：500PCS,Month

Basic Info.

Model NO. 4YZ-4 Harvest method Picking Drive Type Gear Drive Transmission Hard Shaft Certification ISO9001:2008 Color Red Condition New Application Field Agriculture After-Sales Severice Provided Engineers Available to Service Overseas Weight 5010 Kg Function Picker+Thresher+Crushing Transport Package Naked Specification 6010*2590*3320mm Trademark CHMC Origin Henan, China HS Code 8433510090 Production Capacity 500PCS/Month

Product Description

1. Replaceable cutter, suited for different row distance
2. With crushed straw device, can return the straw to field, reclaim the straw, make the straw in rows
3. 5 sets peeling device, improve the peeling efficiency.
4. Big shake sieve, it can collect the corn seed
5. The wheel distance adjustable, can suit different  row distance.
6. Sealed cab, this reduce the noise, make the driver feel more comfortable.
7. Steering wheel in one side of the cab.
8. Technical parameters:

Model	4YZ-4
Type	tyre
Wheel	2 drive wheel, 2 direction wheel
Function	Picker + peeling, produce "corn on the cob"
Model of engine	YC4A140Z-T21
Power	140 hp (103kW)
Engine speed	2200 r/min
Harvester rows	4 rows
Cutting width	2400mm
Harvest efficiency	2.1-3.0 acre/hour
Rows distance	500mm-700mm
Peeling device	4 sets
Total loss rate	≤4%
Breakage rate	≤1.0%
Impurity rate	≤3.0%
Peeling rate	≥85%
Oil consumption	≤8.4Kg/acre
Minimum corn cob height from field	280mm
NW	5010Kg
Size	6010*2590*3320mm

Our factory

Zhengzhou Zhonglian Harvest Machinery Co., Ltd is a professional combine harvester manufacturing company which integrates product research,spare parts producing ,complete machine assembling and product after-sale service. The company was founded in 1995.The company products has 7 series and in total more than 100 types which cover peanut harvester,wheat harvester,rice harvester,corn harvester ,soybean harvester ,corn seeds harvester and silage harvester.In international market,the products mainly are exported to South Asia,Southeast Asia,West Asia,Africe and Middle Europe.
