Sorghum Rice Grain Separator Machine
Hebei Ruixue Grain Selecting Machinery Company Limited- Model：5xz-3
- Capacity(T/H)：3000 Kg,H
- Dimension (L*W*H)：2600*1500*2100
- Weight (Kg)：1300kg
- Function：Remove Immature, Moldy , Insect Damaged Seed
- Application：All Kinds of Seed Grain Bean Pulse and Cereals
Base Info
- Model NO.：5XZ-3
- Warranty：1 Year
- Delivery Time：10-15 Days After Receiving Advance Payment
- Color：White Color
- Advantage：Blowing Type Gravity Separator
- Transport Package：Wooden Case or Container
- Specification：ISO9001: 2008, TUV, SGS SONKAP
- Trademark：SYNMEC grain separator machine
- Origin：China
- HS Code：84371090
- Production Capacity：50 Set,Month
Description
Basic Info.
Model NO. 5XZ-3 Warranty 1 Year Delivery Time 10-15 Days After Receiving Advance Payment Color White Color Advantage Blowing Type Gravity Separator Transport Package Wooden Case or Container Specification ISO9001: 2008, TUV, SGS SONKAP Trademark SYNMEC grain separator machine Origin China HS Code 84371090 Production Capacity 50 Set/MonthProduct Description
5XZ-3 sorghum rice grain separator machineIntroduction of 5XZ-3 sorghum rice grain separator machine
5XZ-3 grain separator machine is the blowing type High Quality Stanard Gravity Separator, used for separating grain and seed which have same shape but different in gravity, finally obtain the best seed which will be used for sowing.
Application of 5XZ-3 sorghum rice grain separator machine
The grain separator machine can efficiently remove moldy kernel, immature shriveled, insect damaged seed or broken seed to ensure maximum quality of the final product. The High Quality Stanard Gravity Separator can be used to separate all kinds of seed and grains, such as coffee bean, cocoa bean, peanuts, corn, peas, beans, rice, wheat, sesame etc.
The vibrating table also has wide applications, from heavy industrial materials like glass, stone, metal and sand, to lighter agricultural seeds beans and nuts.
Working Principle of 5XZ-3 sorghum rice grain separator machine
The grain separator machine works on a fluidized bed principle. Materials is fed on oscillating sieve deck. By the pressure of air & deck oscillation, material is fluidized and stratified. Heavy fraction sink into the deck while light fraction is suspended in fluidized state. Deck oscillation causing heavy and light fraction travel in separated path and collected separately.
Specification of 5XZ-3 sorghum rice grain separator machine
| Model | Capacity (KG/H) | Power(KW) | Weight(KG) | Dimension(mm) |
| 5XZ-3 | 3000 | 7.45 | 1300 | 2600*1500*2100 |
| 5XZ-6 | 5000 | 8.95 | 2000 | 3440*1630*1900 |
| 5XZ-10 | 10000 | 15 | 2500 | 4300*1960*2500 |
