• Model NO.：Corn
• Blade Type：Curved Teeth
• Computerized：Computerized
• Certification：ISO9001:2008, CE, SGS
• Condition：New
• Warranty：1 Years
• Capacity(T/H)：50,12t,H
• Brand Name：Fdsp
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Power(Kw)：2*0.25
• Transport Package：Pallet
• Specification：CE, ISO, SGS
• Trademark：Liangyou
• Origin：China
• HS Code：8436100000
• Production Capacity：50,12tph

Technological process chart:
RM Receiving & Precleaning System-Grinding System-Dosing & Mixing System-Pelleting System-Bagging System-Auxiliary System


Technological characteristics and introductions:
RM receiving and cleaning process: Granule material is dumped and cleaned,  individually dust collected which is with the better effects.
cleaner: granule precleaner SCY100, output 30-50t/h

Grinding process: 3 sets of hammer mill is adopted in this process, 2 grindings bins are equipped for each hammer mill to crush different raw material at the same time which improves the productivity; The impurities could be removed from raw material by magnetic separation equipment before grinding bins to ensure the safe running of hammer mill.
Grinding equipment( 3 sets): Hammer mill(2 sets) SFSP668×1000, 160KW, output 18-25T/H/set( ¢3.0mm screen hole). Hammer mill( 1set) SFSP668*1200,355KW, output 40-50T/H/set( ¢3.0mm screen hole)

Batching and mixing process: in this process, we use 18pcs batching bins, two batching and mixing systems are allocated. Each batching system is allocated with 1 batching scale to work at same time, which is controlled by FDSP developed independently batching program, achieve accurate quick and slow feeding, quick batching and with high accuracy.
Weighing equipment: batching scale PCS30, weighing accuracy: dynamic≤3‰, static≤1‰.
Mixing equipment( 2sets): SHSJ6, (45KW,3000kg/batch), designed output 35-45t/h/set,  homogeneity CV≤5%.

Pelleting process: one set double-layer conditioner pellet mill is used in this process. Two pellet bins are equipped for the pellet mill, which is easy to sift when replacing the varieties. After pelleting, the pellets enter into the cooler, bucket elevator and then go to screening by rotary screener. The finished products go to the packing bins, others screened powder material goes back to the pellet mill.
Pellet mil( 1set): SZLH678, 200KW,output 18-20T/H.
Cooling equipment( 1set): SKLN10,output 20-25T/H.

Packing process: There are 4 FP bins in this process, 2 of them can store both mash feed and pellet feed. There is special anti-grading device for mash feed bins. The pellet feed and mash feed will be weighed and packed finally by packing scale. 16 bulk bins are designed for bulk trucks shipping at the same time.
Packing equipment: Ton packing scale(both for mesh feed and pellet feed), weighing rage 800-1000kg/bag, 6-10bags /min.

Auxiliary process: dust removal system to improve workers' working environment; Grease adding system, commonly added in mixer to improve palatability of feed.


1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Liyang City, Jiangsu Province, China, near Shanghai. You can fly to Shanghai airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
