20L Payload Remote Control Spraying Pesticide Uav Drone
Qingdao Zhongfei Intelligent Technology Co., Ltd.- After-sales Service:24 Hours Oneline Service
- Warranty:One Year After Delivery Date
- Installation:No Installation
- Liquid Contained:Medicine
- Spraying Shape:Full Cone
- Volume:16L~30L
Base Info
- Model NO.:D20L-6
- Power Supply:Electric
- Technics:Assembly
- Material:Aviation Carbon Fiber and Aviation Aluminum
- Type:Sprayer Drone
- Sprayer Type:Pump
- Usage:Agriculture
- Applicable Industry:Farms,Home Use,Epidemic Prevention
- Feature:Anti-Fall
- Production Material:Aviation Carbon Fiber and Aviation Aluminum
- Production Folding Size:2510mm*2510mm*590mm
- Max Pesticide Load:25kg
- Aircraft Medicine Box Capacity:22L
- Flight Radius:Less Than 5000m
- Max Takeoff Weight:45kg
- Aircraft Weight:14-16kg
- Flight Attitude:Less Than 30m
- Flight Duration:13-33minutes
- Condition:New
- Warranty Time:12 Months
- Transport Package:Professional Package Box
- Specification:1 CBM
- Trademark:UNID
- Origin:China
- HS Code:8802200090
- Production Capacity:10000 Unit
Description
Basic Info.
Model NO. D20L-6 Power Supply Electric Technics Assembly Material Aviation Carbon Fiber and Aviation Aluminum Type Sprayer Drone Sprayer Type Pump Usage Agriculture Applicable Industry Farms,Home Use,Epidemic Prevention Feature Anti-Fall Production Material Aviation Carbon Fiber and Aviation Aluminum Production Folding Size 2510mm*2510mm*590mm Max Pesticide Load 25kg Aircraft Medicine Box Capacity 22L Flight Radius Less Than 5000m Max Takeoff Weight 45kg Aircraft Weight 14-16kg Flight Attitude Less Than 30m Flight Duration 13-33minutes Condition New Warranty Time 12 Months Transport Package Professional Package Box Specification 1 CBM Trademark UNID Origin China HS Code 8802200090 Production Capacity 10000 UnitProduct Description
20L payload remote control spraying pesticide UAV drone- OEM & ODM Service -
design makes assemble become easier.There is AB points mode. You can plan spraying route and area via APP software.The arms can be replaced easily if the arm power system has problem. We chose suitable volume and designed package so that it can operate by one.The water tank is specially designed for better anti-sway effect so that the aircraft is more stable.Pay attention to the water at the battery and battery interface, to prevent the danger caused by short circuit during use.
Model | D20L-6 |
Product material | Aviation carbon fiber + aviation aluminum |
Product expansion size | 2510mm*2510mm*590mm |
Product folding size | 660mm*620mm*1310mm |
Packaging size | 1420mm*640mm*720mm |
Maximum takeoff weight | 45KG |
Aircraft weight | 14-16KG |
Pesticide Barrel | 20L~22L |
Flight altitude | ≤30 meters |
Fly time(unloaded) | 20~25 minutes |
Fly time(loaded) | 10~13 minutes when fully loaded |
Flight speed | 1-10 m / sec |
Structure Life Span | ≥10 years |
Spray width | 6-8 meters |
Hovering in the air | Hovering in any direction |
Spray flow | 5-8L/min |
Spray system | Imported high pressure anti-floating atomizing nozzle |
Atomization point size | 60~90μm |
Fly Control | Industrial Version GPS and Controller |
Spary efficiency | ≥7 hectares/day |
Safe takeoff and landing wind speed | ≤5 |
Motor speed | 5000rpm |
Power system | 48V power polymer computer battery |
Charer | AC Input 100-240V |
Lithium-polymer battery | 20000mAh*1 |
