• Model NO.：D30L-8
• Power Supply：Electric
• Technics：Assembly
• Material：Aviation Carbon Fiber and Aviation Aluminum
• Type：Sprayer Drone
• Sprayer Type：Pump
• Usage：Agriculture
• Applicable Industry：Farms,Home Use,Epidemic Prevention
• Feature：Automatic Flight
• Production Material：Aviation Carbon Fiber and Aviation Aluminum
• Production Folding Size：730mm*830mm*1560mm
• Max Pesticide Load：25kg
• Aircraft Medicine Box Capacity：30L
• Flight Radius：Less Than 5000m
• Max Takeoff Weight：75kg
• Aircraft Weight：20kg
• Flight Attitude：Less Than 30m
• Flight Duration：13-40minutes
• Condition：New
• Warranty Time：12 Months
• Transport Package：Professional Package Box
• Specification：0.6 CBM
• Trademark：BORUAV
• Origin：China
• HS Code：8802200090
• Production Capacity：10000 Unit

Basic Info.

Model NO. D30L-8 Power Supply Electric Technics Assembly Material Aviation Carbon Fiber and Aviation Aluminum Type Sprayer Drone Sprayer Type Pump Usage Agriculture Applicable Industry Farms,Home Use,Epidemic Prevention Feature Automatic Flight Production Material Aviation Carbon Fiber and Aviation Aluminum Production Folding Size 730mm*830mm*1560mm Max Pesticide Load 25kg Aircraft Medicine Box Capacity 30L Flight Radius Less Than 5000m Max Takeoff Weight 75kg Aircraft Weight 20kg Flight Attitude Less Than 30m Flight Duration 13-40minutes Condition New Warranty Time 12 Months Transport Package Professional Package Box Specification 0.6 CBM Trademark BORUAV Origin China HS Code 8802200090 Production Capacity 10000 Unit

Product Description

High Quality UAV drones agriculture sprayer drone spraying in agriculture / agricultural drone sprayer / drone sprayer

- OEM  & ODM Service -D30L-8 is suitable for pesticide spraying in farmland. The device also has a line feed function when spraying pesticides. It can also complete automatic spraying of the area by controlling the background, which greatly improves the work efficiency. After spraying the pesticides carried by the 30 kg plant protection drone D30L-8, it can return to the breakpoint to continue the spraying operation, which can avoid repeated spraying. The use of small agricultural drones in large-scale farmland can improve the ability to control pests and diseases in a timely manner.

Model	D30L-8
Product Material	Aviation carbon fiber & aviation aluminum
Airframe Dimensions(Incl. propellers)	3090mm*3090mm*830mm
Airframe Dimensions(folded)	890mm*750mm*1680mm
Transport Dimensions	1800*1000*900mm
Max Takeoff Weight	66KG
Aircraft Weight	26KG
Maximum Capacity(spraying system)	30L
Flight Altitude	≤20m
Flight Time (Unloaded)	15~25 minutes
Flight Time (Full Loaded)	5~13 minutes
Flight Speed	≤15m/s
Spray Width	6-12m
Spray Flow	3-10L/min (5L double water pump)
Nozzle Type	Imported high pressure anti-floating atomizing nozzle
Droplet Size	60~90μm
Flight Controller	Professional industrial version flight controller
Navigation Method	GPS/GNSS RTK
Operating Efficiency	≥12 (ha/hr)
Safe Takeoff and Landing Wind Speed	≤8 m/s
Motor speed	5000rpm
Battery Voltage	50.4V
Battery Capacity	16000mAh*2( 12S Intelligent Lithum Battery)
Battery Lifespan(Cycle)	≥500
Intelligent Charger	AC Input 100-240V
