Mini Harvester---Semi-Feeding Caterpillar Self-Propelled Rice Combine Harvester
Yancheng Benniu Tractor Co., Ltd.- Type:Portable Harvester
- Application:Rice
- Power Source:Diesel
- Harvest method:Vibration fall
- Drive Type:Gear Drive
- Transmission:Soft Shaft
Base Info
- Model NO.:4LBZ-110
- Certification:ISO9001:2008
- Color:Yellow
- Condition:New
- Application Field:Agriculture, Livestock, Aquaculture, Forestry
- Transport Package:Wooden Pallets
- Specification:2510x1300x1690
- Trademark:YANBEN
- Origin:Yancheng China
- HS Code:8701901990
- Production Capacity:1000
Description
Basic Info.
Model NO. 4LBZ-110 Certification ISO9001:2008 Color Yellow Condition New Application Field Agriculture, Livestock, Aquaculture, Forestry Transport Package Wooden Pallets Specification 2510x1300x1690 Trademark YANBEN Origin Yancheng China HS Code 8701901990 Production Capacity 1000Product Description
Technical Parameter4LBZ-110Semi-Feeding Tracked Self-propelled Rice Combiner | |
---|---|
Working state profile size (length * width * height) | 2590mm×1330mm×2010m |
Structural Type | Semi-Feed Crawler Self-propelled Type |
Number of rows | 4 rows |
Cutting table width | 1.1m |
Engine Model | ZH1110/ZS1110/H20 Diesel Engine |
Rating Power of Matching Engine | 14.7kw |
Rated Speed of Matching Engine | 2200/2300r/m |
Fan Type/Diameter(mm)/Blade Number | Centrifugal/φ250/8 |
Number of threshing drums | 2 |
Main threshing drum type | combing belt type |
Main threshing drum dimension outer diameter (outer diameter * length) | stripping strip 1397 * 725 (circumference * width) mm |
Concave Type | Grid Format |
Vibrating Screen Type | / |
Track specifications (pitch * pitch * width ) | 80mm×32×280mm |
Manual bagging of grain | Manual bagging of grain |
Quality of the whole machine | 950kg |
Threshing Type | Comb strip + transverse axial flow pin-tooth type |
Feeding volume | 1.0kg/s |
