Automatic Poultry Farm Broiler Breeder Floor Raising System
HENAN POUL TECH MACHINERY CO., LTD.- Type：Chicks Hatching Machine
- Usage：Raising Chicken
- Application：Chicken
- Power Source：Electric
- Heating and Ventilation Equipment Type：Air Duct
- Epidemic Prevention Equipment：Aerosol Immune Machine
Base Info
- Model NO.：PT-FR17
- Blade Type：Straight Teeth
- Computerized：Computerized
- Certification：ISO9001:2008, CE
- Condition：New
- Transport Package：Carton Boxes
- Specification：300x300x250mm
- Trademark：Poul Tech
- Origin：China
- HS Code：84362900
- Production Capacity：10000
Description
4. Tunnel ventilation system.
Exhaust Fans: 50 inch fans (Box fan or Cone fan), fans with accredited Europe of CE certification.
Guarantee period for fans: One year, the easily damaged parts are offered free of charge.
Description
Blade Diameter (mm)
Frequency (Hz)
Current (A)
Input Power (KW)
Voltage (V)
Rotational Speed (r/min)
Airflow (m3/h)
Size(mm)
Weight (Kg)
50" box fan
1270(50inch)
50
2.8
1.1
380
1440
43170
1380*1380*450
89
50 cone fan
1270(50inch)
50
2.8
1.1
380
1440
51020
1380*1380*1360
100
Evaporation Water cooling pad system: It is best effecitive combiation to decrease the temperature in poultry house in hot cliamte area.
Water cooling pad curtain of broiler poultry farming equipment.
Cooling Paper Size : length: 1.5 m ,1.8m , 2.0 m, width:0.6m, thickness : 0.15m.
Size with aluminum allloy frame : 1.66m ,1.96 m ,2.16 m.
The best air speed getting trough water cooling pad is 1.8 meter /second.
5. Environment control system.
Environment controller: Agrologic 610, Agrologic 616, Rotem AC2000, AC2000 PLUS, according to farm capacity or your requests.
Electric control box: Schneider brand elements.
