Sesame Paddy Wheat Corn Maize Seed Packing Machine
Hebei Ruixue Grain Selecting Machinery Company Limited- Weighing Range(Kg)：5-25
- Power：2.5
- Bagging Speed：Over 360 Bags,H
- Model：Dcs-25b
- Name：Bagging Scale System
- Application：Packing Machine
Base Info
- Model NO.：DCS-50B
- Usage：Grain Packing Machine
- Transport Package：Wooden Case or Container
- Specification：ISO9001-2008, TUV, SGS SONKAP
- Trademark：SYNMEC
- Origin：China
- HS Code：84371090
- Production Capacity：1000 Set,Year
Description
Basic Info.
Model NO. DCS-50B Usage Grain Packing Machine Transport Package Wooden Case or Container Specification ISO9001-2008, TUV, SGS SONKAP Trademark SYNMEC Origin China HS Code 84371090 Production Capacity 1000 Set/YearProduct Description
Sesame Paddy Wheat Corn Maize Seed Packing Machine1.0 Introduction of Sesame Paddy Wheat Corn Maize Seed Packing Machine
bagging scale system is the core and associate with elevator, belt Conveyor, sewing machine and air compressor, those become an electronical quantitative packing line, It's Suitable of packing the granule materiel, such as the seed, agricultural product and chemical etc.
This machine has an ideal control system by adopts advanced microelectronic technologies, it provides perfect Control and management of the production process. The computer part adopts advanced microcontroller MCS-51 series chip, high-performance operational amplifiers, high-speed A / D conversion device and Programmable I / O, that become an automatic control system
3.0 Composition and working principle of Sesame Paddy Wheat Corn Maize Seed Packing Machine
sesame corn wheat paddy rice seed packing bagging scale machine set equipment includes Bagging Scale, elevator, belt conveyor, sewing machine and air Compressor. The elevator's start and stop is automatic control by the two material level detectors in the hopper (high material Level detector and low material level detector). When the low material level detector detects no material in the 3 Top -hopper, it will open the elevator for lifting material into top hopper, it will open the elevator for lifting material into tophopper, it will open the elevator for lifting material into top hopper, it will open the elevator for lifting material into top hopper.
| Model | Weighting Range | Accuracy | Throughput | workin Environment | Power and Bag |
| DCS-10B | 1-10 | 0.2%F.S. | >360 | -10-+40 | 2.5KW 0.3-0.5MPA |
| DCS-25B | 5-25 | 0.2%F.S. | >360 | -10-+40 | 2.5KW |
| DCS-50B | 10-50 | 0.2%F.S. | >240 | -10-+40 | 2.5KW |
