HDPE Tilapia Farming Grow out Fish Net Cage
QINGDAO EVERGROWING IMPORT&EXPORT CO., LTD.- Type：Fisheries Auxiliary Machinery
- Working Method：Fish Farming Cage
- Power Source：No Need of Power
- Harvesting Machinery Type：Fishing Auxiliary Machinery
- Fishing Auxiliary Machinery Type：Nets Fishing Auxiliary Machinery
- Certification：ISO9001:2008
Base Info
- Model NO.：EG01
- Condition：New
- Transport Package：in Bulk
- Specification：Diameter 10m Fish Net 4m
- Origin：China
- HS Code：5608110000
- Production Capacity：15 Sets Per Month
Description
Basic Info.
Model NO. EG01 Condition New Transport Package in Bulk Specification Diameter 10m Fish Net 4m Origin China HS Code 5608110000 Production Capacity 15 Sets Per MonthProduct Description
Circular Fish CageThe circular fish cages are suitable for exposed and semi exposed locations. Available cage sizes ranging from diameter 8m to diameter 40m, aquaculture area up to 1000 cubic meters.
HDPE strong and robust structure
- adaptable to local conditions
- double collar tube and handrail tube in HDPE 100 polyethylene plastic
- injection moulded brackets attached with stoppers and dowels around the full circumference
- evenly distributed pressure throughout the structure
- flexibility, strong, corrosion resistant
1)Anti-Windstorm capacity:Maximum grade 11
2) Ability of anti-wave:Maximum wave high of 5 meter in the water
3) Anti-flow capability:Maximum flow rate of 1.5m
| Structure | Diameter 8m--Diameter 12m | Diameter 15m--Diameter 25m | Diameter 26m--Diameter 40m |
| Floating pipe | HDPEФ200mm | HDPEФ250mm | HDPEФ350mm |
| Handrail pipe | HDPEФ90mm | HDPEФ110mm | HDPEФ110mm |
| Stanchion pipe | HDPEФ90mm | HDPEФ125mm | HDPEФ125mm |
| Cage bracket | HDPE 200 | HDPE 250 | HDPE 315 |
| Stoppers and Pins | HDPE | HDPE | HDPE |
1. Production to Delivery
2. Field Installation
3. Cage Farming
4. Fish Harvest
