• Model NO.：SJ
• Transport Package：Wooden Case
• Specification：5CBM
• Trademark：Tianfeng
• Origin：China
• HS Code：84778000
• Production Capacity：100sets,Month

Basic Info.

Model NO. SJ Transport Package Wooden Case Specification 5CBM Trademark Tianfeng Origin China HS Code 84778000 Production Capacity 100sets/Month

Product Description

   We are Zhejiang Tianfeng Plastic Machinery Co.,LTD in China.We are manufactures PP Woven Bag Making Machine and PP twine Rope Making Machines more than 20 years
   We are profession manufactures complete line PP Twine Making Machines,Like PP Flat Yarn Extruder line with Heavy Duty Winder Machines,Bale Twine Twist and Re-winder Machine and so on
    Please do not hesitate to contact me if you are interested in our machines
    With best regards

Model	SJPL-Z65/30-700/112	SJPL-Z90/33-1000/160	SJPL-Z100/30-1200/192	SJPL-Z120/30-1500/256
Max. extrusion capacity	180kg/h	280kg/h	350kg/h	490kg/h
Motor of extruder	60kw	90kw	120kw	160kw
Dia. of screw	65mm	90mm	100mm	120mm
Ratio of screw L/D	30:1	33:1	30:1	30:1
Revolution of screw	20~160r/min	20~120r/min	30~120r/min	30~120r/min
Width of die	700mm	1000mm	1200mm	1500mm
Max. winding speed	280m/min	280m/min	280m/min	280m/min
Range of flat yarn fibre	60~200tex	60~200tex	60~200tex	60~200tex
Stretching ratio	4~10	4~10	4~10	4~10
Number of winder	112spindles	160spindles	192spindles	256spindles
System installed capacity	237kw	300kw	320kw	400kw
Normal operational capacity	160kw	180kw	190kw	230kw
Weight (About)	20000kg	27000kg	30000kg	32000kg
Overall dimension (L×W×H)	26500×3200×2600	32000×3200×2600	35000×3200×2600	39000×3200×260
