Fertilizer Pellet Machine Flat Die 3 Roller Compost Machine
Zhengzhou Hanghui Machinery Equipment Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Type：Fertilizer Granulator Machine
- Voltage：380V
- Certification：CE, ISO
- Transport Package：Wooden Case
Base Info
- Model NO.：KJ-320
- Specification：0.8-1.0Ton per Hour
- Trademark：HH
- Origin：China
- Production Capacity：0.8-1.0ton Per Hour
Description
Overview
Product Description
2. Features of Fertilizer Pellet Machine Flat Die 3 roller Compost Machine:
·The produced particles are columnar or spherical.
·Realize the granulation of pure organic matter.
·Using the characteristic that organic particles can grow up inlaid with each other under a certain force, there is no need to add a binder when granulating.
·The granules are solid and can be sieved after granulation, reducing drying energy consumption.
·The organic matter after fermentation does not need to be dried, and the moisture content of the raw material can be 20-30%.
1. Application of Fertilizer Pellet Machine Flat Die 3 roller Compost Machine:
The Fertilizer Pellet Machine Flat Die 3 roller Compost Machine is used to granulate various organic substances after fermentation.2. Features of Fertilizer Pellet Machine Flat Die 3 roller Compost Machine:
·The produced particles are columnar or spherical.
·Realize the granulation of pure organic matter.
·Using the characteristic that organic particles can grow up inlaid with each other under a certain force, there is no need to add a binder when granulating.
·The granules are solid and can be sieved after granulation, reducing drying energy consumption.
·The organic matter after fermentation does not need to be dried, and the moisture content of the raw material can be 20-30%.
3. Working principle of Fertilizer Pellet Machine Flat Die 3 roller Compost Machine:
The XKJ series oblique wheel flat die pellet machine is based on the circular motion of the machine. The motor acts as the power to drive the gear to transmit to the main shaft and the flat die. Under the action of friction, the pressure wheel rotates to make the pressure between the pressure wheel and the template. The high friction temperature makes the powdery material gelatinized at high temperature, and the protein is coagulated and denatured. It is extruded from the die hole under the extrusion of the pressure wheel, and the pellets are then sent out of the machine through the discharge port through the spinning plate. .- Product Parameters
6.Technical specifications of the Flat Die Organic Fertilizer Pellet Machine:
Model Power Die Diameter Capacity Dimension Weight KJ-320 22kw Ø2- Ø20 0.8-1.0T/Hour (Ø4) 1800*730*1400mm 648kg KJ-420 37kw Ø2- Ø20 1.5-2.0T/Hour (Ø4) 1810*830*1650mm 930kg KJ-550 55kw Ø2- Ø20 2.0-3.0T/Hour (Ø4) 2000*1150*1700mm 1800kg KJ-650 75kw Ø2- Ø20 3.0-5.0T/Hour (Ø4) 2100*1260*1880mm 2530kg
